PVC Grey Plastic Rod - 18mm To 30mm Dia.


Price
Sale price £14.84 | (Inc. VAT)

Description

Unplasticised Polyvinyl Chloride
  • U-PVC is rated self-extinguishing, has excellent chemical resistance with high mechanical and tensile strength, together with a high degree of stability. U-PVC is easily weldable but has a limited operating temperature range of 0°C to +60°C.

Applications:

  • Air conditioning ventilation systems
  • Corrosive fluid handling
  • Water applications
  • Valves
  • Tanks

Properties:

  • Relatively less expensive than other plastics
  • Machines well to a polished finish
  • Food compliant grades available
  • Flame retardant grades available
  • UV stabalised grades available
  • Solvent Cemented Welded
  • Drinking water approved
  • Chemical resistant
  • Self extinguishing
  • Strong and stiff

WHAT ARE THE ADVANTAGES OF PVC PLASTIC ROD?

  • PVC Plastic Rod has good hardness and mechanical properties
  • Excellent electrical insulating properties
  • Very high chemical resistance
  • Very good moisture resistance
  • Good dimensional stability
  • Easily bondable and an excellent engineering plastic for welding
  • Self-extinguishing
  • Fairly inexpensive

WHAT ARE THE DISADVANTAGES OF PVC PLASTIC ROD?

  • The heat stability of PVC isn’t great– when the temperature reaches 140°C PVC starts to decompose and its melting temperature is 160°C
  • PVC is a good insulator but its electrical insulating property is not as good as polyethylene or polypropylene
  • It is generally only suitable for medium or low voltage and low frequency insulation materials

HOW DOES PVC PLASTIC ROD PERFORM?

  • Most products made with PVC are long lasting – up to and over 60 years. Because of this reliability throughout their service lives, maintenance or repair is reduced significantly. It is the most widely used material in building and construction applications. PVC is resistant to oxidation and degradation and its inherent chlorine content gives it excellent fire resistance.

WHAT IS PVC PLASTIC ROD USED FOR?

  • Common applications include chemical processing tanks, valves, fittings piping systems. In addition, other applications include:
  • Pump components
  • Electrical insulators
  • Acid tanks
  • Templates
  • Fabricated fittings
  • Battery boxes

WHY NOT TO USE PVC PLASTIC ROD?

  • PVC Plastic Rod isn’t really a high wear application material like nylon or UHMWPE and also probably shouldn’t be used for components that will come into constant contact with food products or require great flexibility, low friction, or high temperature resistance.

WHAT ARE THE MACHINING CHARACTERISTICS OF PVC PLASTIC ROD?

  • PVC is reasonably hard. If possible use double edged milling cutters. When sawing using a circular saw, use saw blades with hard metal-inserted teeth and a tooth spacing of 10 to 20 mm as this has been found to be especially effective.

DOES PVC PLASTIC ROD HAVE CHEMICAL RESISTANCE?

  • In general, PVC is suitable to withstand most strong acids, alkalis, aqueous solutions that are not strongly oxidizing, aliphatic hydro carbons, fluorides, photographic and plating solutions, brine, mineral oils, fats and alcohols. However, PVC Plastic Rod should not normally be used with aldehydes and ketones, ethers, cyclic ethers, esters and aromatic and chlorinated hydrocarbons, nitro compounds, some petrol / benzene mixtures and similar solvents which lead to a marked swelling and softening of the material.

WHAT ARE THE UNIQUE CHARACTERISTICS OF PVC PLASTIC ROD?

  • PVC pipes have recently been analysed after in-ground use for over 35 years and have shown no detectable corrosion or degradation and have been estimated to possess at least another 50 years of service life.

IS PVC PLASTIC ROD KNOWN AS ANYTHING ELSE?

  • Other Trade names (also known as):
  • Boltaron®
  • Geon®
  • Vintec®
  • Corzan®

WHAT IS THE SIZE RANGE AND AVAILABILITY OF PVC PLASTIC ROD?

  • Our PVC Plastic Rods are available in grey colour from stock but black, red and cream is available within a day or two from order and in diameters ranging from 6m up to 300mm.

IS IT EASY TO GLUE AND BOND PVC PLASTIC ROD?

  • Gluing or bonding PVC is very easy, but is usually permanent and so cannot be easily undone. The only way to correct any bonding mistakes is to cut away the glued area. High frequency welding (gluing) is possible.

IS PVC PLASTIC ROD OKAY FOR FOOD APPLICATIONS?

  • PVC Plastic Rod is not FDA approved and so direct and or permanent contact isn’t recommended.

DOES PVC PLASTIC ROD HAVE GOOD WEAR RESISTANCE?

  • PVC Plastic Rod exhibits only reasonable resistance to high wear and abrasion. PVC is pretty tough and you will find PVC being used all over the place.

WHY SHOULD YOU CHOOSE PVC PLASTIC ROD?

  • PVC Plastic Rod is an pretty durable material that is stronger than some other plastics. It can typically withstand impacts many times that which completely shatter components made of Acrylic or Styrene.
  • PVC is also extremely chemical resistant and resists attack or degradation from a wide range of chemicals, making it the material of choice in many tough industrial applications, as well as very good electrical insulation properties.

IS THERE A SUMMARY OF PVC PLASTIC ROD?

  • PVC Plastic Rod is a durable material that is resistant to chemicals, acids, weather and abrasion. It can be machined and tooled into a vast variety of shapes and components. It is strong yet relatively lightweight, affordable and widely available. While it has a low melting point in comparison to some other plastics it has a good fire rating, it has a service life that will outlast the person who works with it!
