Cut to size calculator
Prices include VAT and cutting. Several pieces of the same size are cut from one piece of stock where they fit, allowing 4mm for the saw blade between pieces; the first piece is cut free and each additional piece is £1.60. Cut pieces are made to order and have a sawn finish. Delivery is calculated at checkout. For shapes, holes or large quantities, request a quote or call 01744 520110.
Description
High Density Polyethylene (HDPE) Rod is a versatile engineering plastic known for its lightweight and strong properties. Ideal for various applications in the food industry and beyond.
Material Properties
High Density Polyethylene (HDPE) is a lightweight material with a specific gravity of 0.96. It exhibits excellent sliding properties, good chemical resistance, and low moisture absorption. HDPE maintains high impact strength even at low temperatures, ranging from -50°C to +80°C.
Performance Characteristics
HDPE Rod is recognized for its good low-temperature resistance and low density. It also boasts good electrical properties and is compliant for food applications, making it suitable for various environments.
Applications
HDPE Rod is commonly used in pumps, tank construction, gaskets, medical applications, and components for the food industry. Its wear resistance and low friction make it advantageous in bearings and rollers.
Advantages and Considerations
While HDPE Rod is economical and easy to machine, it can be difficult to bond using adhesives. However, its lightweight nature and low friction properties are beneficial in many applications. It is particularly effective where abrasion resistance is required without extreme loads.
Specifications
- Material: High Density Polyethylene (HDPE)
- Specific Gravity: 0.96
- Temperature Range: -50°C to +80°C
- Food Compliant: Yes
- Low Water Absorption: Yes
- Good Electrical Properties: Yes
Benefits
- Cost-effective and economical
- Low friction for enhanced performance
- Good wear and abrasion resistance
- Easy to machine for various applications
Use Cases
- Pumps
- Tank construction
- Gaskets
- Medical applications
- Components for the food industry
FAQ
Q: Can HDPE Rod be used for food applications?
A: Yes, HDPE Rod is food compliant and often used in food production environments.
Q: Is HDPE Rod suitable for wear resistance?
A: Yes, HDPE Rod is very good for wear resistance in applications with low loads.
Q: What are the disadvantages of HDPE Rod?
A: HDPE Rod can be difficult to bond with adhesives, and it is not the hardest engineering plastic.
All sizes & prices
8 sizes · prices include VAT · tap a price to select that size
| Diameter Length | 100mm | 250mm | 500mm | 1000mm |
|---|---|---|---|---|
| 250mm | £249.74£2,497.40/m | £567.58£2,270.32/m | £1,081.10£2,162.20/m | £2,059.24£2,059.24/m |
| 300mm | £358.60£3,586.00/m | £815.04£3,260.16/m | £1,552.44£3,104.88/m | £2,957.02£2,957.02/m |
Need a size that isn't listed? We cut to order. Request a quote or call 01744 520110.
