Description
This clear extruded acrylic tube is a high-quality, rigid plastic tubing designed for applications where visibility, durability and a clean, professional finish are essential. Manufactured from transparent acrylic, it offers excellent clarity, making it ideal for viewing, display and fluid indication tasks where you need to see exactly what is happening inside the tube.
Supplied in a standard full length of 2000mm, this clear acrylic tube is available in a choice of outer and inner diameters from 28mm OD x 24mm ID through to multiple 30mm OD combinations, plus several further sizes. It is commonly used in fabrication, model making, retail display, protective guards, light diffusers and general engineering projects that require a lightweight yet robust transparent tube.
Product Features
- Clear extruded acrylic tube with excellent optical transparency for maximum visibility.
- Available diameters include 28mm OD x 24mm ID, 30mm OD x 26mm ID, 30mm OD x 24mm ID, 30mm OD x 22mm ID and 30mm OD x 20mm ID, plus additional size options.
- Standard full length of 2000mm, suitable for cutting down to shorter lengths as required.
- Rigid, dimensionally stable construction for neat, straight runs and accurate assemblies.
- Smooth internal and external surfaces for clean flow paths and an attractive finish.
- Manufactured from clear acrylic (PMMA) for a good balance of strength, stiffness and light weight.
- Supplied in a neutral clear colour to blend with a wide range of designs and installations.
Key Features and Benefits
- High clarity material allows easy visual inspection of contents, flow or components inside the tube.
- Lightweight alternative to glass, helping to reduce handling risks and installation loads.
- Good impact and scratch resistance for long-lasting, presentable installations in demanding environments.
- Easy to cut, drill and bond with appropriate tools and adhesives, simplifying custom fabrication work.
- Weather and UV-resistant properties make it suitable for many indoor and covered outdoor applications.
- Consistent wall thickness and sizing across the range for repeatable, professional results in production runs.
Specifications
| Specification | Detail |
|---|---|
| Material | Clear extruded acrylic (PMMA) |
| Available diameters (OD x ID) | 28mm x 24mm, 30mm x 26mm, 30mm x 24mm, 30mm x 22mm, 30mm x 20mm, plus additional OD/ID combinations |
| Standard length | 2000mm (full length tube) |
| Colour | Clear, transparent |
| Form | Rigid extruded tube with smooth bore and outer surface |
| Typical tolerance | Standard extrusion tolerances on OD, ID and wall thickness (check individual size data if critical) |
Applications and Ideal Uses
This clear acrylic tube is suitable for a wide variety of display, protection and light-duty engineering tasks where a transparent, rigid tube is required.
- Retail and point-of-sale displays, product stands and visual merchandising.
- Protective guards, covers and safety barriers around moving or delicate parts.
- Model making, architectural prototypes and craft projects requiring clear structural elements.
- Light fittings, LED sleeves and other illumination or decorative applications.
- Visual level indicators or demonstration rigs in educational and laboratory settings.
Frequently Asked Questions
Can I cut the 2000mm acrylic tube to shorter lengths myself?
Yes, the tube can be cut to size using suitable tools such as a fine-toothed saw or a mitre saw with a blade suitable for plastics. Support the tube firmly, cut slowly to avoid chipping, and lightly deburr the edges after cutting for a clean finish.
Is this clear acrylic tube suitable for use outdoors?
Acrylic has good resistance to weathering and UV light, so the tube can be used in many outdoor or semi-exposed applications. However, for long-term external use in harsh conditions, you should assess the installation carefully and ensure the tube is properly supported and protected from excessive mechanical stress.
Can this tube be used for pressurised liquids or compressed air lines?
This extruded acrylic tube is primarily intended for display, protective covers and light-duty flow indication rather than high-pressure service. It is not generally recommended for pressurised systems without a full engineering assessment of wall thickness, operating pressure and safety factors.
