The Professional PE300 (HDPE) Extruded Natural Rod is a high-performance polyethylene product characterized by its exceptional chemical resistance, very high impact strength, and extremely low moisture absorption. With a long-term service temperature range from -50°C to 80°C and a short-term maximum service temperature of 100°C, this rod is durable and reliable in various conditions. The water absorption factor is less than 0.01g/cm³, ensuring that the PE300 (HDPE) Rod remains dimensionally stable even in humid environments.
This product is ideal for applications in construction, drinking and wastewater technology, as well as in the bottling and food industries. The PE300 (HDPE) Rod is particularly well-suited for machining processes such as billeting, precision grinding, and CNC turning.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PE300 (HDPE) |
| Shape | Rod |
| Colour | Natural |
| Density (g/cm³) | 0.95 |
| Yield stress (MPa) | 22 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | 12 |
| Shore hardness (scale D) | 63 |
| Tensile modulus of elasticity (MPa) | 800 |
| Melting temperature (°C) | 135 |
| Thermal conductivity (W/(m*K) | 0.4 |
| Thermal capacity (kJ/(kg*K) | 1.9 |
| CLTE (10⁻⁶K⁻¹) | 150…230 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 80 |
| Service temp short term max (°C) | 100 |
| Heat deflection temperature (°C) | 67 |
| Dielectric constant | 2.4 |
| Dielectric strength (kV/mm) | 45 |
| Volume resistivity (Ω*cm) | >10¹⁴ |
| Surface resistivity (Ω) | >10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Construction
- Drinking and Wastewater Technology
- Bottling Industry
- Food Industry
FAQ
- What is the temperature range for PE300 (HDPE) Rod? The long-term service temperature range is from -50°C to 80°C, with a short-term maximum of 100°C.
- What industries can benefit from using PE300 (HDPE) Rod? It is commonly used in construction, water technology, and food industries.
- Can PE300 (HDPE) Rod be machined? Yes, it is suitable for billeting, precision grinding, and CNC turning.
