Description
Description
Professional Engineering Grade Extruded Clear Rod is a high performance, amorphous thermoplastic with exceptional product characteristics, including high dimensional stability, low moisture absorption, and excellent rigidity. This material is ideal for various applications, including electrical and electronic industries, safety engineering, and vehicle construction.
The long-term service temperature range of this Professional Engineering Grade Rod is from -40°C to 115°C, with a short-term maximum service temperature of 140°C. It is particularly well-suited for machining, precision grinding, and CNC turning, making it a versatile choice for professionals in need of reliable performance.
Note: Engineering Grade Polycarbonate is not optically clear and should be utilized for its technical and mechanical properties rather than its aesthetic qualities.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Engineering Grade Polycarbonate |
| Shape | Rod |
| Colour | Clear |
| Density (g/cm³) | 1.2 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 65 |
| Elongation at break (%) | 80 |
| Notched impact strength (kJ/m²) | 20 |
| Ball indentation hardness (MPa) | 130 |
| Shore hardness (scale D) | 82 |
| Tensile modulus of elasticity (MPa) | 2300 |
| Thermal conductivity (W/(m*K) | 0.21 |
| Thermal capacity (kJ/(kg*K) | 1.2 |
| CLTE (10⁻⁶K⁻¹) | 70 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 115 |
| Service temp short term max (°C) | 140 |
| Heat deflection temperature (°C) | 135 |
| Dielectric constant | 3 |
| Dielectric strength (kV/mm) | 30 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹⁵ |
Applications
- Electrical and electronic industries
- Safety engineering
- Vehicle construction
- Precision machining and CNC turning
FAQ
- Is this material suitable for outdoor use? Yes, it has good UV resistance.
- Can it be easily machined? Yes, it is suitable for precision machining techniques.
- What is the maximum temperature it can withstand? The short-term maximum service temperature is 140°C.
