Description
Description
The Premium Glass Fibre Angles are pultruded in a polyester matrix to BS EN 13706 specifications. The fiberglass layup consists of a combination of multi-layered cross-ply glass fibre fabrics, providing enhanced strength across the axis for excellent mechanical properties.
Glass Fibre offers numerous advantages, including lightweight construction and a high strength-to-weight ratio that ensures reliable performance even under heavy loads. Its versatility and ease of handling make it a practical and cost-effective choice for a wide range of structural applications, while its resistance to corrosion makes it ideal for demanding environments. Glass Fibre can be easily machined and cut to size, allowing for customization to meet the unique requirements of your project.
This high-performance material combines durability with ease of handling and installation, making it an ideal solution for various applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Glass Fibre |
| Shape | Angle Trim |
| Colour | White |
| Density (g/cm³) | 1.5-2 |
| Water absorption (%) | 0.5-2 |
| Construction | Pultrusion |
| Resin Matrix | Polyester |
| Fibre Orientation | Crossdirectional |
| CLTE (10⁻⁶K⁻¹) | 7.2 |
| Full Section Modulus | < 6mm thick: E17 (GPa17), 6mm >: E23 (GPa23) |
| Tensile strength axial (MPa) | E17: 170, E23: 240 |
| Tensile strength transverse (MPa) | E17: 30, E23: 50 |
| Flexural strength axial (MPa) | E17: 170, E23: 240 |
| Flexural strength transverse (MPa) | E17: 70, E23: 100 |
| Tensile modulus axial (MPa) | E17: 1.7x10⁴, E23: 2.4x10⁴ |
| Tensile modulus transverse (MPa) | E17: 0.5x10⁴ |
Dimensions & Specifications
Dimensions are critical for ensuring the right fit for your project. The angles can be customized to meet specific requirements.
FAQ
- What are the main benefits of using Glass Fibre? Glass Fibre is lightweight, corrosion-resistant, and offers high strength-to-weight ratio, making it perfect for structural applications.
- Can Glass Fibre be customized? Yes, Glass Fibre can be easily machined and cut to size for specific project needs.
- What standards does the product meet? The product is manufactured to BS EN 13706 specifications, ensuring quality and reliability.
