Description
Description
The Premium UPVC Extruded Red Rod is a synthetic polymer known for its exceptional resistance to acids, lyes, and salt solutions. This rod exhibits flame retardant properties, ensuring self-extinguishment upon removal of a flame. It is designed for easy processing through methods such as welding, thermoforming, and bonding, making it an ideal choice for various applications.
With a long-term service temperature range from 0°C to 60°C and a short-term maximum service temperature of 70°C, the UPVC Rod is suitable for use in environments where moderate thermal resistance is required. Typical applications include chemical engineering, tank building, and pump engineering, making it a versatile material for various industrial uses.
Additionally, the UPVC Rod is well-suited for precision machining, grinding, and CNC turning, allowing for customization to meet specific project requirements.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | UPVC |
| Shape | Rod |
| Colour | Red |
| Density (g/cm³) | 1.44 |
| Yield stress (MPa) | 50 |
| Elongation at break (%) | 15 |
| Notched impact strength (kJ/m²) | 4 |
| Ball indentation hardness (MPa) | 120 |
| Shore hardness (scale D) | 80 |
| Tensile modulus of elasticity (MPa) | 3200 |
| Melting temperature (°C) | 216 |
| Thermal conductivity (W/(m*K)) | 0.2 |
| CLTE (10⁻⁶K⁻¹) | 80 |
| Service temp long term min (°C) | 0 |
| Service temp long term max (°C) | 60 |
| Service temp short term max (°C) | 70 |
| Heat deflection temperature (°C) | 60 |
| Dielectric constant | 3 |
| Dielectric strength (kV/mm) | 32 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | VO |
| Flammability 6mm | VO |
| Material type | Extruded |
Applications
- Chemical engineering
- Tank building
- Pump engineering
- Precision machining
- CNC turning
FAQ
- What is the maximum temperature this rod can withstand? The short-term maximum service temperature is 70°C.
- Can this rod be machined? Yes, it is well-suited for precision machining and CNC turning.
- Is this material resistant to chemicals? Yes, it has high resistance to acids, lyes, and salt solutions.
