Description
Description
The Premium UPVC Black Hollow Rod is a synthetic polymer renowned for its high mechanical strength, tensile strength, and hardness. This material offers exceptional chemical resistance and features flame retardant properties, ensuring self-extinguishing capabilities upon removal of flame. The hollow rod is easy to process through welding, thermoforming, and bonding, making it ideal for various applications.
Notable characteristics include low water absorption and good insulation properties, particularly beneficial for electronics. The long-term service temperature range for this hollow rod is from 0°C to 60°C, making it suitable for a variety of environments.
Typical fields of application for the Premium UPVC Hollow Rod include:
- Machine parts
- Chemical engineering
- Tank building
- Pump engineering
This material is well suited for billeting, precision grinding, and CNC turning. If you need machined or finished components, please inquire for more information.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | UPVC |
| Shape | Hollow Rod |
| Colour | Black |
| Density (g/cm³) | 1.44 |
| Yield stress (MPa) | 56 |
| Elongation at break (%) | 14 |
| Notched impact strength (kJ/m²) | 4 |
| Shore hardness (scale D) | 81 |
| Tensile modulus of elasticity (MPa) | 3350 |
| Thermal conductivity (W/(m*K) | 0.14 |
| CLTE (10⁻⁶K⁻¹) | 80 |
| Service temp long term min (°C) | 0 |
| Service temp long term max (°C) | 60 |
| Dielectric constant | 3 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | 10¹³ |
| Surface resistivity (Ω) | 10¹³ |
FAQ
-
What is the maximum service temperature for this hollow rod?
The maximum long-term service temperature is 60°C. -
Can this material be used for electronic insulation?
Yes, it has good insulation properties for electronics. -
Is this hollow rod suitable for CNC machining?
Yes, it is well suited for precision grinding and CNC turning.
