Description
Description
Premium UPVC Extruded White Sheet is a synthetic polymer known for its exceptional properties, including high resistance to acids, lyes, and salt solutions. This material boasts flame retardant characteristics, self-extinguishing after the removal of the flame, making it suitable for various industrial applications. The easy processing methods such as welding, thermoforming, and bonding enhance its usability in diverse projects.
This UPVC sheet has a long-term service temperature range from 0°C to 60°C and can withstand a short-term maximum service temperature of up to 70°C. Its versatility makes it ideal for fields such as chemical engineering, tank building, and pump engineering, as well as applications involving CNC routing and milling.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | UPVC |
| Shape | Sheet |
| Colour | White |
| Density (g/cm³) | 1.44 |
| Yield stress (MPa) | 50 |
| Elongation at break (%) | 15 |
| Notched impact strength (kJ/m²) | 4 |
| Ball indentation hardness (MPa) | 120 |
| Shore hardness (scale D) | 80 |
| Tensile modulus of elasticity (MPa) | 3200 |
| Melting temperature (°C) | 216 |
| Thermal conductivity (W/(m*K) | 0.2 |
| CLTE (10⁻⁶K⁻¹) | 80 |
| Service temp long term min (°C) | 0 |
| Service temp long term max (°C) | 60 |
| Service temp short term max (°C) | 70 |
| Heat deflection temperature (°C) | 60 |
| Dielectric constant | 3 |
| Dielectric strength (kV/mm) | 32 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | V0 |
| Flammability 6mm | V0 |
| Material type | Extruded |
Applications
This UPVC sheet is suitable for various applications, including:
- Chemical engineering
- Tank building
- Pump engineering
- CNC routing and milling
FAQs
What is the maximum service temperature for this sheet?
The short-term maximum service temperature is 70°C.
Can this material be easily processed?
Yes, it can be processed through welding, thermoforming, and bonding.
Is this sheet suitable for outdoor use?
Yes, it has high resistance to various chemicals and can be used in outdoor applications.
