The Premium UPVC Extruded Black Rod is a synthetic polymer offering exceptional characteristics, including high resistance to acids, lyes, and salt solutions. It features flame retardant properties, self-extinguishing after the removal of flame, and is easy to process through methods such as welding, thermoforming, and bonding. The long-term service temperature range of this rod is from 0°C to 60°C, with a short-term maximum service temperature of 70°C.
This versatile rod is ideal for various applications in chemical engineering, tank building, and pump engineering. The UPVC Rod is particularly well-suited for precision grinding, CNC turning, and billeting. Other similar materials available include PE300 (HDPE) Extruded Black Rod and PE500 (HMWPE) Extruded Natural Rod.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | UPVC |
| Shape | Rod |
| Colour | Black |
| Density (g/cm³) | 1.44 |
| Yield Stress (MPa) | 50 |
| Elongation at Break (%) | 15 |
| Notched Impact Strength (kJ/m²) | 4 |
| Ball Indentation Hardness (MPa) | 120 |
| Shore Hardness (Scale D) | 80 |
| Tensile Modulus of Elasticity (MPa) | 3200 |
| Melting Temperature (°C) | 216 |
| Thermal Conductivity (W/(m*K)) | 0.2 |
| CLTE (10⁻⁶K⁻¹) | 80 |
| Long Term Service Temp Min (°C) | 0 |
| Long Term Service Temp Max (°C) | 60 |
| Short Term Service Temp Max (°C) | 70 |
| Heat Deflection Temperature (°C) | 60 |
| Dielectric Constant | 3 |
| Dielectric Strength (kV/mm) | 32 |
| Volume Resistivity (Ω*cm) | 10¹⁵ |
| Surface Resistivity (Ω) | 10¹³ |
| Comparative Tracking Index | 600 |
| Flammability 3mm | VO |
| Flammability 6mm | VO |
| Material Type | Extruded |
Applications
This UPVC Extruded Black Rod is suitable for numerous industrial applications including:
- Chemical engineering
- Tank building
- Pump engineering
- Precision grinding
- CNC turning
FAQ
What is the maximum service temperature for the UPVC Rod?
The maximum short-term service temperature is 70°C.
Can this rod be easily processed?
Yes, it can be processed by welding, thermoforming, and bonding.
What are the flame retardant properties of this rod?
The rod is self-extinguishing after the removal of flame, ensuring safety in applications.
