Description
This premium multilayer thermoplastic rubber hose is designed for the safe transfer of aggressive liquids, chemicals and industrial fluids in demanding environments. Constructed from high‑performance thermoplastic rubber with a robust multilayer structure, it offers excellent flexibility, durability and chemical resistance while maintaining a smooth internal surface for reliable flow.
Ideal for use in factories, processing plants, workshops and maintenance operations, this crush‑resistant hose is suitable for applications where hoses may be dragged, bent or lightly compressed during use. Available in a wide range of diameters and coil lengths, it can be specified to match fixed installations, mobile equipment or general service duties across many industries.
Product Features
- Multilayer thermoplastic rubber construction for enhanced durability and resistance to aggressive liquids.
- Available outside/inside diameters from 28 mm up to 47 mm (plus 11 additional size options for precise system matching).
- Coil lengths from 19 m, 25 m, 30 m, 32 m and 35 m, with a further 11 length options to suit fixed runs or mobile hose lines.
- Smooth internal surface to minimise friction losses and help reduce product residue build‑up.
- Highly flexible hose design for easy routing around machinery, pipework and confined spaces.
- Crush‑resistant structure to withstand occasional compression, traffic and rough handling in busy working areas.
- Temperature‑tolerant thermoplastic rubber suitable for a wide range of industrial and maintenance environments.
Key Features and Benefits
- Provides reliable transfer of aggressive liquids and chemicals, helping to reduce the risk of leaks and hose failure.
- Flexible yet robust design improves handling and makes installation faster, even in tight or complex routing paths.
- Crush‑resistant construction offers extra protection in high‑traffic zones where hoses may be stepped on or lightly driven over.
- Smooth bore design promotes efficient flow, reducing pressure drop and making the hose easier to flush and clean.
- Wide choice of diameters and coil lengths allows closer matching to existing systems, minimising waste and excess hose.
- Thermoplastic rubber materials support long service life, helping to lower replacement frequency and maintenance downtime.
Specifications
| Specification | Detail |
|---|---|
| Material | Multilayer thermoplastic rubber hose with smooth internal surface |
| Outside/Inside Diameter Options | 28 mm, 35.5 mm, 40.5 mm, 42.5 mm, 47 mm plus 11 additional diameter variants |
| Coil Length Options | 19 m, 25 m, 30 m, 32 m, 35 m plus 11 additional coil length variants |
| Design Features | Flexible, crush‑resistant construction with smooth bore for aggressive liquids |
| Pressure/Temperature Use | Typical industrial hose for transfer of liquids; confirm operating pressure and temperature before use |
| End Connections | Compatible with standard hose tails, clamps and fittings sized to the selected hose diameter |
Applications and Ideal Uses
This thermoplastic rubber hose is suited to a wide range of industrial liquid‑handling tasks, particularly where aggressive or challenging fluids are present and flexibility is essential.
- Chemical transfer lines in production, mixing or dosing areas.
- Industrial cleaning and maintenance hoses for machinery and plant washdown (where chemically compatible).
- Process plant connections for transferring aggressive liquids between fixed equipment.
- Mobile service units and maintenance trolleys requiring flexible, crush‑resistant hose runs.
- General industrial fluid handling in workshops, factories and utilities facilities.
Frequently Asked Questions
Is this thermoplastic rubber hose suitable for all types of aggressive liquids?
The hose is designed for aggressive liquids, but chemical compatibility should always be checked against the specific media, concentration, temperature and operating conditions. Refer to a chemical compatibility chart for thermoplastic rubber or consult your safety data sheets and technical guidance before use.
Can this hose be used where it may occasionally be stepped on or lightly compressed?
Yes, the hose has a crush‑resistant construction intended to cope with occasional compression and rough handling in industrial environments. However, it should not be used where it will be subjected to continuous heavy loads, sharp edges or repeated severe crushing without suitable protection.
How do I choose the correct diameter and coil length for my installation?
Select a diameter that matches your existing fittings and required flow rate, checking both outside and inside dimensions for compatibility with hose tails and clamps. For coil length, measure the full run of the installation, including bends and routing around obstacles, then choose the nearest standard coil length that provides a little extra allowance without excessive surplus hose.
