Description
This premium soft PVC hose is reinforced with a galvanised steel spiral to provide a flexible yet robust solution for the transfer of food-grade liquids. Designed to maintain excellent flow characteristics, it offers a smooth internal bore and reliable performance across a wide range of diameters and coil lengths to suit your installation or process requirements.
Ideally suited to food and beverage environments, this crush-resistant hose performs reliably in temperature conditions from -5°C to +65°C. Typical applications include the transfer of water, juices and other compatible food liquids in processing plants, dairies, bottling lines, mobile catering units and general industrial settings where hygiene and flexibility are essential.
Product Features
- Soft PVC hose construction with integrated galvanised steel spiral for reinforced strength and stability.
- Available in a wide range of outside/inside diameters, including 16, 18, 20, 22 and 24.5 mm, plus a further selection of larger and smaller sizes.
- Supplied in convenient coil lengths of 10, 12, 14, 16 and 18 metres, with additional coil length options to match your installation needs.
- Engineered temperature operating range from -5°C to +65°C for dependable performance in chilled and warm environments.
- Flexible wall design for easy handling, routing and installation in tight or complex layouts.
- Optimised spiral spacing and wall thickness to provide excellent crush resistance and kink resistance.
- Food-liquid compatible PVC formulation suitable for the transfer of many common food and beverage media (subject to compatibility checks).
Key Features and Benefits
- Highly flexible and easy to route – Soft PVC body and spiral reinforcement allow the hose to bend smoothly around equipment, reducing the need for fittings and saving installation time.
- Crush-resistant construction – Galvanised steel spiral helps the hose retain its shape under compression, minimising flow restriction and downtime.
- Reliable performance across a broad temperature range – Operates from -5°C to +65°C, making it suitable for both cool-room environments and warmer processing areas.
- Smooth internal bore – Promotes efficient flow of liquids and helps reduce pressure loss and potential areas where residues can accumulate.
- Versatile sizing and coil options – Multiple diameter and coil length combinations mean you can specify a hose that closely matches your system requirements, reducing waste and joins.
- Durable and long-lasting – Quality PVC compound and corrosion-resistant steel spiral provide good resistance to wear and mechanical stress in demanding food and industrial environments.
Specifications
| Specification | Detail |
|---|---|
| Material | Soft PVC hose with galvanised steel spiral reinforcement |
| Outside/Inside Diameter Options | Common sizes include 16, 18, 20, 22 and 24.5 mm (plus a further range of additional diameters) |
| Standard Coil Lengths | 10, 12, 14, 16 and 18 m coils, with further coil length options available |
| Temperature Range | -5°C to +65°C (approximate operating range) |
| Reinforcement | Embedded galvanised steel spiral for crush and kink resistance |
| Typical Pressure Capability | Suitable for low to medium pressure transfer of compatible food liquids (exact working pressure dependent on hose size and installation) |
Applications and Ideal Uses
This flexible spiral-reinforced PVC hose is designed for the safe and efficient transfer of compatible food liquids in a variety of processing and handling environments.
- Food and beverage processing lines for conveying water, juices and other suitable liquids.
- Dairies and creameries for non-fatty liquid transfer and wash-down water supply (subject to media compatibility).
- Mobile catering units, food trucks and temporary food installations requiring a flexible supply hose.
- General industrial liquid transfer where a flexible, crush-resistant hose is required.
- Filling, bottling and packaging operations connecting tanks, pumps and filling machinery.
Frequently Asked Questions
Is this hose suitable for all food liquids, including oils and fats?
The hose is designed for use with many common food liquids, but suitability for oils and fats depends on the specific media and conditions. Always check chemical compatibility data for soft PVC with your particular product, especially for high-fat or high-temperature applications.
Can the hose be used outdoors or in mobile applications?
Yes, the flexible construction and crush-resistant galvanised steel spiral make it suitable for many outdoor and mobile uses, such as mobile catering or temporary installations. As with any PVC hose, prolonged exposure to direct sunlight and weathering may affect service life, so visual inspection and routine replacement are recommended.
How do I select the correct diameter and coil length for my system?
Measure the connection sizes on your equipment to determine the required inside diameter, and consider the desired flow rate to minimise pressure loss. For coil length, follow the intended hose route and add a margin for bends and movement. A range of diameters (including 16, 18, 20, 22 and 24.5 mm) and multiple coil lengths (10, 12, 14, 16 and 18 m, plus additional options) are available to help you choose the closest match.
