Description
The Premium Semi Rigid Nylon Tube is manufactured using a high viscosity extrusion grade Nylon 12 (Polyamide 12, PA12). This high-performance material offers good chemical resistance and excellent resistance to weathering, along with significantly lower water absorption compared to Nylon 6. The tube is designed to operate effectively within a temperature range of -40°C to +80°C, making it suitable for various applications.
Technical Specifications
| Specification |
Measurement |
| Material |
Nylon 12 |
| Shape |
Tube |
Dimensions & Specifications
| Outside/Inside Diameter |
Working Pressure (BAR) |
Burst Pressure (BAR) |
| 1/8" / 0.062" |
101 |
403 |
| 1/8" / 0.075" |
80 |
320 |
| 5/32" / 0.096" |
77 |
308 |
| 3/16" / 0.107" |
86 |
343 |
| 3/16" / 0.117" |
75 |
301 |
| 3/16" / 0.137" |
54 |
215 |
| 1/4" / 0.15" |
80 |
320 |
| 1/4" / 0.17" |
64 |
256 |
| 1/4" / 0.19" |
48 |
192 |
| 5/16" / 0.182" |
84 |
334 |
| 5/16" / 0.212" |
64 |
257 |
| 5/16" / 0.242" |
45 |
180 |
FAQ
-
What is the maximum operating temperature for this tube? The tube can operate within a temperature range of -40°C to +80°C.
-
What material is the tube made from? It is made from high viscosity Nylon 12, offering excellent chemical resistance.
-
What is the significance of the working pressure ratings? The working pressure figures are based on the theoretical burst pressure at 20°C using a 1:4 safety factor. Increased temperatures will decrease pressure capabilities.
