The Premium Extruded Satin Tube is a high-quality product featuring a frosted surface on both the interior and exterior faces. With a light transmission rate of 70%, this tube ensures a consistent light level without spotting when paired with the correct source of illumination. It showcases excellent resistance to mechanical stress, a hard surface, and outstanding thermal stability. The long-term service temperature range for this extruded acrylic product is from -20°C to 60°C.
Typical applications for the Premium Extruded Satin Tube include set design for film and television, retail display, and lighting design. It is well-suited for fabrication, gluing, and CNC turning processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Tube |
| Colour | Satin |
| Density (g/cm³) | 1.19 |
| Water absorption (%) | 0.21 |
| Elongation at break (%) | 3 |
| CLTE (10⁻⁶K⁻¹) | 80 |
| Thermal conductivity (W/(m*K) | 0.19 |
| Service temp long term min (°C) | -20 |
| Service temp long term max (°C) | 60 |
| Dielectric constant | 2.9 |
| Dielectric strength (kV/mm) | 35 |
| Material type | Extruded |
FAQ
- What is the light transmission of the Premium Extruded Satin Tube? The light transmission is 70%.
- What temperature range can the product withstand? The service temperature range is from -20°C to 60°C.
- What are the typical applications of this acrylic tube? It is used in set design, retail displays, and lighting design.
