Description
Description
The Premium High-Performance Pressed and Planed Red Polyethylene Sheet is a superior material that exhibits exceptional properties including high chemical resistance, very high impact strength, and extremely low moisture absorption. This sheet is designed to maintain dimensional stability even in humid environments, making it suitable for a wide range of applications.
With a long-term service temperature range of 100°C to 80°C and a short-term maximum service temperature of 100°C, this polyethylene sheet is ideal for use in environments that require durability and reliability. Its water absorption factor is less than 0.01%, ensuring that it remains stable and functional under various conditions.
Typical applications for this sheet include:
- Chemical engineering and tank building
- Drinking and wastewater technology
- Bottling and food industries
The Premium High-Performance Red Polyethylene Sheet is also suitable for CNC routing, CNC milling, and welding, making it versatile for various manufacturing processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PE 500 (HMWPE) |
| Shape | Sheet |
| Colour | Red |
| Density (g/cm³) | 0.96 |
| Yield stress (MPa) | 27 |
| Elongation at break (%) | >50 |
| Shore hardness (scale D) | 65 |
| Tensile modulus of elasticity (MPa) | 1200 |
| Melting temperature (°C) | 135 |
| Thermal conductivity (W/(m*K) | 0.4 |
| Thermal capacity (kJ/(kg*K) | 1.9 |
| CLTE (10⁻⁶K⁻¹) | 150…230 |
| Service temp long term min (°C) | 100 |
| Service temp long term max (°C) | 80 |
| Service temp short term max (°C) | 100 |
| Heat deflection temperature (°C) | 79 |
| Dielectric constant | 2.3 |
| Dielectric strength (kV/mm) | 45 |
| Volume resistivity (Ω*cm) | >10¹⁴ |
| Surface resistivity (Ω) | >10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
FAQ
Q: What is the maximum service temperature for this sheet?
A: The maximum service temperature is 100°C for short-term use.
Q: Can this material be welded?
A: Yes, this polyethylene sheet is suitable for welding and CNC machining.
Q: What industries commonly use this product?
A: It is commonly used in chemical engineering, water treatment, and food industries.
