Description
Description
Our Recycled Acetal C sheet is made from 100% Recycled Acetal C and possesses properties equivalent to those of virgin Acetal C. Typical characteristics include:
- Continuous operating temperature from -40 °C to +100 °C
- High rigidity (to -40 °C)
- High thermal stability
- High dimension stability
- Low water absorption
- Good electrical insulating properties
- High strength and stiffness
- Very good sliding properties
- High resistance to solvents
- Very high resistance to stress cracks
Due to its resistance to hot water and various chemical agents, this material is frequently utilized in applications within the food industry. Other applications include components for pumps, bearings, fittings, gear wheels, and parts for the textile industry.
If you have a requirement for machined or finished Acetal C components, please inquire for further information.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acetal C |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 1.39 |
| Water absorption (%) | 0.8 |
| Yield stress (MPa) | 67 |
| Elongation at break (%) | 28 |
| Notched impact strength (kJ/m²) | 6 |
| Ball indentation hardness (MPa) | 125 |
| Shore hardness (scale D) | 83 |
| Tensile modulus of elasticity (MPa) | 2855 |
| Melting temperature (°C) | 166 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 100 |
| Dielectric constant | 3.8 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | ≥10¹³ |
| Surface resistivity (Ω) | ≥10¹³ |
| Comparative tracking index | 600 |
| Flammability | HB |
| Material type | Extruded |
FAQ
-
What are the key benefits of using Recycled Acetal C?
It offers high rigidity, thermal stability, low water absorption, and excellent electrical insulation properties. -
In what applications is Recycled Acetal C commonly used?
This material is ideal for food industry applications, pumps, bearings, and parts in the textile industry. -
Can Recycled Acetal C be machined?
Yes, it can be machined or finished into specific components as per requirements.
