Description
Description
This premium recycled acetal C rod is manufactured from 100% recycled acetal C, offering properties that are equivalent to those of virgin acetal C. It is designed for high-performance applications with the following characteristics:
- Continuous operating temperature from -40 °C to +100 °C
- High rigidity at low temperatures down to -40 °C
- Excellent thermal stability and dimension stability
- Low water absorption for enhanced durability
- Good electrical insulating properties
- High strength and stiffness, suitable for demanding applications
- Very good sliding properties
- High resistance to solvents and stress cracks
Due to its resistance to hot water and various chemical agents, this recycled acetal C rod is frequently utilized in the food industry. Additionally, it is suitable for manufacturing parts for pumps, bearings, fittings, gear wheels, and components in the textile industry.
If you have specific requirements for machined or finished acetal C components, please inquire for more information.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acetal C |
| Shape | Rod |
| Colour | Black |
| Density (g/cm³) | 1.39 |
| Water absorption (%) | 0.8 |
| Yield stress (MPa) | 67 |
| Elongation at break (%) | 28 |
| Notched impact strength (kJ/m²) | 6 |
| Ball indentation hardness (MPa) | 125 |
| Shore hardness (scale D) | 83 |
| Tensile modulus of elasticity (MPa) | 2855 |
| Melting temperature (°C) | 166 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 100 |
| Dielectric constant | 3.8 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | ≥10¹³ |
| Surface resistivity (Ω) | ≥10¹³ |
| Comparative tracking index | 600 |
| Flammability | HB |
| Material type | Extruded |
Applications
This premium recycled acetal C black rod is ideal for various applications including:
- Food industry components
- Parts for pumps and bearings
- Fittings and gear wheels
- Textile industry components
FAQ
-
What is the operating temperature range?
The operating temperature range is from -40 °C to +100 °C. -
Is this material resistant to chemicals?
Yes, it has high resistance to various chemical agents. -
What are the mechanical properties?
The material has high strength, stiffness, and very good sliding properties.
