Description
Description
Our Premium Rectangular Glass Fibre Tubes are pultruded in a polyester matrix to BS EN 13706 specifications. The fibreglass layup is a combination of multi-layered cross-ply glass fibre fabrics, providing enhanced across-axis strength for exceptional mechanical properties.
Glass Fibre Tubes offer numerous benefits including a lightweight construction and a high strength-to-weight ratio, ensuring reliable performance even under heavy loads. Their versatility and ease of handling make them a practical, cost-effective choice for a wide range of structural applications, while their resistance to corrosion makes them ideal for demanding environments. They can be easily machined and cut to size, allowing for easy customization to meet the unique requirements of your project.
Offering high performance and durability combined with ease of handling and installation, Premium Glass Fibre Tubes are an ideal solution for various applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Glass Fibre |
| Shape | Rectangular Tube |
| Colour | White |
| Density (g/cm³) | 1.8 |
| Water absorption (%) | 0.5-2 |
| Construction | Pultrusion |
| Resin Matrix | Polyester |
| Fibre Orientation | Crossdirectional |
| CLTE (10⁻⁶K⁻¹) | 7.2 |
| Barcol hardness | 40-70 |
| Tensile strength (MPa) | 500 |
| Flexural strength (MPa) | Up to 13.8 mm dia: 650 |
| Over 13.8 mm dia: | 450 |
| Compressive strength (MPa) | Up to 13.8mm dia: 190 |
| Over 13.8mm dia: | 150 |
| Tensile modulus (MPa) | 2.7x10⁴ |
| Flexural modulus (MPa) | Up to 13.8mm dia: 3.0x10⁴ |
| Over 13.8mm dia: | 2.4x10⁴ |
| Heat distortion temp (°C) | 125-145 |
| Dielectric strength (kV/mm) | 25 |
| Surface resistivity (Ω) | 10¹⁰-10¹⁵ |
| Volume resistivity (Ω) | 10¹⁵ |
Frequently Asked Questions
-
What are the benefits of using glass fibre tubes?
They offer lightweight construction, high strength-to-weight ratio, and corrosion resistance, making them ideal for various structural applications. -
Can glass fibre tubes be customized?
Yes, they can be easily machined and cut to size to meet specific project requirements. -
What is the tensile strength of these tubes?
The tensile strength is rated at 500 MPa, ensuring reliability under heavy loads.
