Premium Pressed Natural Sheet is a vinylidene-fluoride-based polymer with exceptional characteristics, including outstanding UV resistance, high purity, and excellent chemical resistance. The long-term service temperature range of this sheet is from -50°C to 140°C, with a short-term maximum service temperature of 150°C.
With virtually no moisture absorption, excellent machinability, and high purity, this material is ideal for applications in chemical engineering, electrical and semiconductor industries, and food processing. It is well-suited for CNC routing, CNC milling, and welding, making it a versatile choice for various projects.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PVDF |
| Shape | Sheet |
| Colour | Natural |
| Density (g/cm³) | 1.78 |
| Yield stress (MPa) | 55 |
| Elongation at break (%) | 30 |
| Notched impact strength (kJ/m²) | 12 |
| Ball indentation hardness (MPa) | 130 |
| Shore hardness (scale D) | 80 |
| Tensile modulus of elasticity (MPa) | 2100 |
| Melting temperature (°C) | 178 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Thermal capacity (kJ/(kg*K) | 1.2 |
| CLTE (10⁻⁶K⁻¹) | 140 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 140 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 115 |
| Dielectric constant | 9 |
| Dielectric strength (kV/mm) | 21 |
| Volume resistivity (Ω*cm) | 10¹⁴ |
| Surface resistivity (Ω) | 10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | VO |
| Flammability 6mm | VO |
Applications
- Chemical Engineering
- Electrical & Semiconductor Industries
- Food Processing
FAQ
-
What is the temperature range for this sheet?
The long-term service temperature range is from -50°C to 140°C, with a short-term maximum of 150°C. -
Can this material be used for CNC machining?
Yes, it is well-suited for CNC routing, milling, and welding. -
What industries utilize this product?
This sheet is ideal for chemical engineering, electrical, semiconductor, and food processing industries.
