Description
This premium PVCu metric pressure pipe is designed for demanding fluid handling systems where reliability, safety and long service life are essential. Manufactured to a PN16 rating, it is suitable for operating pressures up to 16 bar, making it ideal for both industrial and commercial installations.
Lightweight yet robust, the pipe is easy to transport, cut and install on site, helping to reduce labour time and overall project costs. Its excellent chemical resistance and smooth internal bore make it a dependable choice for water treatment, chemical processing, irrigation, HVAC and a wide range of general engineering applications.
Product Features
- Available in a range of metric outside diameters including 16 mm, 20 mm, 25 mm, 32 mm and 40 mm, plus additional larger sizes for system flexibility.
- Multiple wall thickness options such as 1.2 mm, 1.5 mm, 1.9 mm, 2.4 mm and 3 mm (and further sizes) to meet different pressure and design requirements.
- Supplied in convenient 2500 mm and 5000 mm lengths to suit compact installations or longer straight runs with fewer joints.
- Manufactured from unplasticised PVC (PVCu) for high rigidity, dimensional stability and long-term performance under pressure.
- PN16 pressure rating for use in systems operating up to 16 bar (at appropriate temperature conditions).
- Smooth internal bore minimises friction losses and supports efficient flow rates in pressure pipework systems.
- Compatible with standard metric PVCu pressure fittings, valves and accessories for straightforward system design.
Key Features and Benefits
- High pressure capability: PN16 / 16 bar rating supports use in demanding pressure applications, reducing the risk of leaks or bursts when correctly installed.
- Lightweight and easy to handle: Considerably lighter than metal pipework, simplifying transport, lifting and installation while reducing support requirements.
- Chemical and corrosion resistance: PVCu construction resists many common chemicals and will not rust, scale or corrode, helping to maintain water quality and system cleanliness.
- Low maintenance and long service life: Durable material with smooth bore reduces blockages and wear, cutting the need for frequent maintenance or replacement.
- Clean, smooth flow path: Internal surface minimises pressure drop and energy loss in pumped systems, supporting efficient operation.
- Versatile sizing options: Wide choice of diameters, wall thicknesses and lengths allows precise system design and easy integration into new or existing pipework.
Specifications
| Specification | Detail |
|---|---|
| Material | Unplasticised polyvinyl chloride (PVCu) pressure pipe |
| Outside diameter options | 16 mm, 20 mm, 25 mm, 32 mm, 40 mm (plus additional larger metric sizes) |
| Wall thickness options | 1.2 mm, 1.5 mm, 1.9 mm, 2.4 mm, 3 mm (and further thicknesses depending on diameter) |
| Standard lengths | 2500 mm and 5000 mm straight lengths |
| Pressure rating | PN16 – suitable for systems up to 16 bar (subject to temperature and design conditions) |
| Colour / finish | Typical industrial grey PVCu for easy identification and a professional installation appearance |
Applications and Ideal Uses
This PVCu PN16 pressure pipe is suitable for a broad range of fluid handling systems where a reliable, corrosion-resistant and easy-to-install solution is required.
- Potable and process water distribution in commercial and industrial facilities (subject to local approvals).
- Chemical dosing and transfer lines in water treatment, laboratories and light chemical processing.
- Irrigation, horticultural and agricultural water supply pipework.
- Chilled water, cooling circuits and low-temperature HVAC services.
- General engineering, plant services and industrial pipework systems using compatible PVCu fittings.
Frequently Asked Questions
Can this PVCu pressure pipe be used for hot water applications?
The pipe is primarily designed for cold and mildly elevated temperature fluids. PVCu has a reduced pressure rating at higher temperatures, so it is generally not recommended for sustained hot water or steam service. Always check the pressure–temperature rating for your operating conditions before use.
How is the pipe joined to fittings and valves?
This metric PVCu pressure pipe is typically joined using solvent cement sockets or, where specified, threaded or flanged adapters. Ends are cut square, cleaned and then bonded into compatible PVCu pressure fittings following the solvent cement manufacturer’s instructions and relevant installation standards.
Is the pipe suitable for underground installation?
The pipe can be used below ground if it is correctly installed with suitable bedding, backfill and protection from point loading or mechanical damage. Local regulations, soil conditions and system design must be taken into account, and care should be taken to avoid direct exposure to heavy vehicular loads without appropriate protection.
