Description
This premium PVCu inch pressure pipe is designed for reliable performance in demanding fluid handling systems. Manufactured to Class C standards and rated to 9 bar, it offers excellent strength, durability and flow efficiency for both potable water and compatible chemical applications.
Available in a choice of popular imperial sizes and standard 3 m or 6 m lengths, this pressure pipe is ideal for new installations, system upgrades and maintenance work. Its corrosion-resistant construction makes it a long-lasting alternative to metal pipework across industrial, commercial, agricultural and building services environments.
Product Features
- Imperial inch sizes available: 2", 3", 4", 5", 6" and 8" for compatibility with common PVCu pressure fittings.
- Standard pipe lengths of 3000 mm and 6000 mm to suit both compact layouts and long straight runs.
- Class C pressure rating, designed for working pressures up to 9 bar in suitable operating conditions.
- Manufactured from rigid unplasticised PVC (PVCu) for excellent dimensional stability and impact resistance.
- Suitable for potable (drinking) water applications when installed as part of an appropriate system.
- Good chemical resistance to a wide range of acids, alkalis and salts for use in industrial and process systems.
- Smooth internal bore to minimise frictional losses, helping to maintain consistent flow rates.
Key Features and Benefits
- Corrosion-free alternative to metal pipework, reducing the risk of rust, scale build-up and contamination in water and chemical lines.
- Lightweight construction makes handling, cutting and installation easier and safer, especially on site or at height.
- Consistent wall thickness and smooth bore support efficient flow, helping to optimise pump performance and energy use.
- Chemical and UV-resistant material provides long service life in demanding industrial and outdoor environments when correctly supported and protected.
- Range of inch sizes and standard lengths simplifies system design and integration with existing PVCu pipework and fittings.
- Low maintenance requirements over the service life of the system can help reduce downtime and overall operating costs.
Specifications
| Specification | Detail |
|---|---|
| Material | Unplasticised polyvinyl chloride (PVCu) |
| Available nominal sizes | 2", 3", 4", 5", 6", 8" (inch pressure pipe) |
| Standard lengths | 3000 mm and 6000 mm |
| Pressure rating | Class C, 9 bar working pressure (at 20 °C, subject to correct design and installation) |
| Application suitability | Potable water distribution and compatible chemical handling systems |
| Installation | For use with matching PVCu pressure fittings using solvent cement or mechanical joints as specified |
Applications and Ideal Uses
This PVCu Class C pressure pipe is suited to a wide range of water and chemical distribution systems where reliable 9 bar performance and corrosion resistance are required.
- Potable water supply lines in commercial, industrial and agricultural buildings.
- Process water and cooling water circuits in manufacturing and plant rooms.
- Chemical dosing, treatment and distribution systems handling compatible media.
- Irrigation and horticultural watering networks requiring durable, low-maintenance pipework.
- General industrial plumbing, wash-down and service water installations.
Frequently Asked Questions
Is this PVCu pressure pipe suitable for drinking water installations?
Yes, this pipe is suitable for potable water when installed as part of an appropriate system using compatible fittings and jointing materials. Always follow relevant water supply regulations and local guidelines when designing and installing drinking water pipework.
Can the pipe be used for hot water or high-temperature applications?
This PVCu pressure pipe is primarily intended for cold and ambient temperature services, such as cold potable water and compatible chemical handling at typical process temperatures. For elevated temperature or hot water systems, check the pressure/temperature derating for PVCu and confirm suitability, or consider alternative materials designed for higher temperatures.
How is the pipe joined and what fittings should I use?
The pipe is designed for use with matching PVCu inch pressure fittings. Joints are typically made using suitable PVCu solvent cement or mechanical couplings, depending on system requirements. Always ensure pipe ends are cut square, cleaned and prepared correctly before jointing, and follow the cement manufacturer’s instructions for curing times.
