Description
This premium PVCu double union ball valve provides reliable on/off control for industrial pipework systems. Manufactured with plain metric sockets and EPDM seals, it offers a durable, corrosion-resistant solution for managing the flow of water and compatible process fluids.
Designed for use across a wide range of industrial and commercial applications, this valve is ideal for chemical handling, water treatment, irrigation, HVAC systems and general pipework installations. The double union design allows the valve body to be removed for maintenance or replacement without disturbing the rest of the pipework.
Product Features
- Premium PVCu construction for excellent chemical and corrosion resistance
- Double union design for easy installation, removal and maintenance
- Plain metric sockets suitable for solvent weld connections
- EPDM seals for reliable, long-lasting sealing performance with water and compatible media
- Available in a wide size range: 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm and 90mm
- Quarter-turn ball operation for straightforward open/close control
- Robust handle for clear position indication and manual operation
Key Features and Benefits
- Provides secure shut-off and flow control, helping to protect downstream equipment and processes.
- Double union ends allow the valve to be serviced or replaced without cutting or disturbing fixed pipework, minimising downtime.
- PVCu body offers a lightweight alternative to metal valves, simplifying handling and installation while resisting rust and many chemicals.
- EPDM sealing elements deliver dependable leak-tight performance and reduced maintenance over the valve’s service life.
- Plain sockets allow strong, permanent solvent weld joints, creating a robust and pressure-capable pipeline system.
- Wide choice of metric sizes enables matching to common PVCu industrial and process pipework dimensions.
Specifications
| Specification | Detail |
|---|---|
| Body material | PVCu (unplasticised polyvinyl chloride) |
| Seal material | EPDM (ethylene propylene diene monomer) |
| Connection type | Plain metric sockets for solvent weld |
| Available sizes | 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm |
| Operation | Manual quarter-turn ball valve with lever handle |
| Typical applications | Water treatment, industrial pipework, irrigation, general service duties |
Applications and Ideal Uses
This PVCu double union ball valve is suitable for a variety of industrial and commercial installations where reliable isolation and ease of maintenance are required.
- Water treatment and filtration systems in commercial and industrial facilities
- Chemical dosing and process lines compatible with PVCu and EPDM
- Irrigation, horticultural and agricultural pipework networks
- Heating, cooling and general service pipework in plant rooms
- Industrial washdown, circulation and utility water systems
Frequently Asked Questions
Can this PVCu ball valve be used with hot water or aggressive chemicals?
The valve is suitable for many cold and mildly warm water applications and certain chemicals compatible with PVCu and EPDM. For hot water, steam or aggressive chemicals, always check the temperature and chemical resistance of both PVCu and EPDM against your specific operating conditions before use.
How is this double union ball valve connected to the pipework?
The valve features plain metric sockets designed for solvent weld connections to matching PVCu pipe. A suitable solvent cement and cleaner should be used, following the cement manufacturer’s instructions, to achieve a strong, permanent joint.
Can the valve be removed for maintenance without cutting the pipe?
Yes. The double union design allows the unions at each end of the valve to be undone, so the central valve body can be removed for inspection, cleaning or replacement without cutting or disturbing the fixed pipework.
