Description
This premium PVCu ball valve with single union plain metric sockets and EPDM seals provides reliable on/off control for water and many compatible liquids in low to medium pressure systems. Designed for straightforward solvent-weld installation into metric pipework, it delivers smooth operation and dependable shut-off performance.
Ideal for use in industrial process lines, water treatment systems, irrigation, swimming pools and general building services, this valve offers a durable, corrosion-resistant alternative to metal valves. The combination of robust PVCu construction and quality EPDM seals ensures long service life with minimal maintenance.
Product Features
- Manufactured from hard-wearing PVCu for strength, rigidity and long-term durability.
- Available in a range of metric sizes: 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm and 90mm.
- Single union design allows easy removal of the valve body for inspection, maintenance or replacement.
- Plain metric sockets suitable for solvent-weld connection into compatible PVCu pipe systems.
- EPDM seals offer reliable sealing performance with water and a wide range of compatible chemicals.
- Full-bore ball design helps minimise pressure loss and supports efficient system flow.
- Manually operated handle for positive, quarter-turn open/close control.
Key Features and Benefits
- Corrosion-resistant construction: PVCu body and union resist rust and many aggressive environments better than traditional metal valves.
- Quick and simple installation: Plain metric sockets allow straightforward solvent-weld joining to existing PVCu pipework without special tooling.
- Reduced downtime: Single union body can be disconnected on one side only, making servicing or replacement faster and less disruptive.
- Reliable sealing performance: EPDM seals help ensure tight shut-off, reducing the risk of leaks and product loss.
- Energy-efficient flow: Full-bore design cuts down on unnecessary pressure drop, supporting efficient pump and system performance.
- Versatile size range: Multiple metric options make it suitable for small distribution lines through to larger process or circulation systems.
Specifications
| Specification | Detail |
|---|---|
| Body material | PVCu (unplasticised polyvinyl chloride) |
| Available sizes | 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm (metric plain sockets) |
| Connection type | Single union, plain metric solvent-weld sockets |
| Seal material | EPDM (ethylene propylene diene monomer) elastomer |
| Operation | Manual quarter-turn lever handle, on/off isolation |
| Typical media | Water and compatible non-aggressive liquids (check chemical compatibility before use) |
Applications and Ideal Uses
This PVCu ball valve is suitable for a wide variety of water and fluid management systems where reliable isolation and easy maintenance are required.
- Industrial and commercial water distribution and treatment pipework.
- Swimming pools, spas and leisure facility filtration and circulation systems.
- Irrigation, horticultural and agricultural water control lines.
- Building services pipework in plant rooms and utility areas.
- Light chemical handling and process lines (subject to chemical compatibility checks).
Frequently Asked Questions
Can this PVCu ball valve be used with hot water systems?
The valve is generally intended for use with cold or mildly warm water and compatible liquids within the temperature range suitable for PVCu and EPDM. For continuous high-temperature or very hot water applications, a different valve material may be required. Always check the system temperature against PVCu and EPDM performance limits.
How do I connect this valve to my existing pipework?
The valve has plain metric sockets designed for solvent-weld connection to PVCu pipe of the matching size. Cut the pipe square, clean and dry the surfaces, then apply suitable PVCu solvent cement according to the adhesive manufacturer’s instructions before inserting the pipe fully into the socket and allowing it to cure.
Can the valve be serviced or replaced without cutting the pipe?
Yes. The single union design allows the valve body to be unscrewed from one side, enabling removal for inspection, seal replacement or substitution of the valve without cutting the connected pipework, provided adequate access and installation space were allowed.
