Description
Description
The Premium Pressed and Planed Natural PPH Sheet is engineered for exceptional performance, featuring high strength and remarkable heat resistance. This high-performance material exhibits excellent chemical and corrosion resistance, making it ideal for demanding applications.
With a long-term service temperature range from 0°C to 100°C and a short-term maximum service temperature of 150°C, this PPH sheet is suitable for a variety of applications, including chemical engineering, tank building, and laboratory technology. Its versatility allows for CNC routing, welding, and fabrication, catering to diverse industry needs.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPH |
| Shape | Sheet |
| Colour | Natural |
| Density (g/cm³) | 0.91 |
| Water absorption (%) | <0.10 |
| Yield stress (MPa) | 32 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | 4 |
| Shore hardness (scale D) | 72 |
| Tensile modulus of elasticity (MPa) | 1300 |
| Melting temperature (°C) | 167 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | 0 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 90 |
| Dielectric constant | 2.4 |
| Dielectric strength (kV/mm) | 45 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Pressed/Planed |
Applications
- Chemical Engineering
- Tank Building
- Laboratory Technology
- CNC Routing and Fabrication
FAQs
-
What is the maximum service temperature for PPH Sheet?
The short-term maximum service temperature is 150°C. -
Is the PPH Sheet suitable for CNC routing?
Yes, it is well suited for CNC routing, welding, and fabrication. -
What applications can the PPH Sheet be used for?
It is ideal for chemical engineering, tank building, and laboratory technology.
