Description
Description
Our Premium Plastic Angle Trim profiles are engineered for versatile applications including corner protection, trimming, and beading. These profiles are constructed from high-performance PPH (Homopolymeric Polypropylene), known for its low density and impressive heat deflection temperature. The material offers good rigidity and hardness, and is resistant to stress cracking. With excellent chemical resistance, it is ideal for various environments.
Choose from a variety of sizes to suit your design needs, ensuring a perfect fit for every project.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Material | PPH |
| Shape | Angle Trim |
| Colour | Light Grey |
| Density (g/cm³) | 0.91 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 32 |
| Elongation at break (%) | ≥30 |
| Notched impact strength (kJ/m²) | 50 |
| Shore hardness (scale D) | 77 |
| Melting temperature (°C) | 160 |
| CLTE (10⁻⁶K⁻¹) | 150 |
| Service temp long term min (°C) | 5 |
| Service temp long term max (°C) | 100 |
| Heat deflection temperature (°C) | 96 |
| Dielectric constant | 2.3 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | >10¹³ |
| Surface resistivity (Ω) | >10¹³ |
| Material type | Extruded |
Features & Benefits
- Durable PPH material ensures longevity and reliability.
- Low density and high heat deflection temperature make it suitable for various environments.
- Good rigidity and hardness for effective corner protection.
- Excellent chemical resistance, ideal for multiple applications.
FAQ
Q: What applications can the Plastic Angle Trim be used for?A: It can be used for corner protection, trimming, and beading in various projects.
Q: What is the maximum service temperature for this product?A: The maximum service temperature is 100°C.
Q: Is this material resistant to stress cracking?A: Yes, the PPH material is not prone to stress cracking.
