Description
Description
The Premium PE300 HDPE Extruded Natural Sheet is a high-performance polyethylene known for its exceptional characteristics. This material features high chemical resistance, very high impact strength, and extremely low moisture absorption. The long-term service temperature range for this sheet is from -50°C to 80°C, with a short-term maximum service temperature of 100°C. Its water absorption factor is less than 0.01%, ensuring dimensional stability even in humid environments.
This versatile sheet is suitable for various applications, including construction, drinking and wastewater technology, and the bottling and food industries. It is well-suited for CNC routing, CNC milling, and welding, making it a preferred choice for many industrial applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PE300 (HDPE) |
| Shape | Sheet |
| Colour | Natural |
| Density (g/cm³) | 0.95 |
| Yield stress (MPa) | 22 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | 12 |
| Shore hardness (scale D) | 63 |
| Tensile modulus of elasticity (MPa) | 800 |
| Melting temperature (°C) | 135 |
| Thermal conductivity (W/(m*K)) | 0.4 |
| Thermal capacity (kJ/(kg*K)) | 1.9 |
| CLTE (10⁻⁶K⁻¹) | 150…230 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 80 |
| Service temp short term max (°C) | 100 |
| Heat deflection temperature (°C) | 67 |
| Dielectric constant | 2.4 |
| Dielectric strength (kV/mm) | 45 |
| Volume resistivity (Ω*cm) | >10¹⁴ |
| Surface resistivity (Ω) | >10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
The Premium PE300 HDPE Extruded Natural Sheet is ideal for:
- Construction
- Drinking water technology
- Wastewater technology
- Bottling and food industries
Frequently Asked Questions
What is PE300 HDPE used for?
PE300 HDPE is commonly used in construction, water technology, and the food industry due to its high chemical resistance and durability.
Is PE300 HDPE safe for food contact?
Yes, PE300 HDPE is suitable for applications in the food industry.
Can PE300 HDPE be machined?
Yes, it is well-suited for CNC routing, CNC milling, and welding, allowing for precision machining.
