Description
Description
Premium PETG sheets offer high impact strength, good fire rating, and are fully recyclable. They are particularly lightweight, weather-resistant, and exhibit extreme break resistance even at low temperatures. The opal UV sheets are translucent white with excellent light diffusion and UV stability.
These sheets are easily fabricated and possess superior thermoforming properties. They can be rapidly thermoformed at low temperatures, ensuring low energy consumption and short production cycles, which saves time and cost. Additionally, they can be printed with standard screen printing equipment, outperforming acrylic in crosshatch tests.
Premium PETG provides almost unlimited freedom of design for creating three-dimensional parts. Typical applications include outdoor displays, poster pillars, vending machines, poster boards, and outdoor advertising boards.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PETG |
| Shape | Sheet |
| Colour | Opal 2130 |
| Density (g/cm³) | 1.27 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 45 |
| Elongation at break (%) | 35 |
| Tensile modulus of elasticity (MPa) | 2020 |
| Notched impact strength (kJ/m²) | 6 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term max (°C) | 65 |
| Heat deflection temperature (°C) | 63-70 |
| Melting temperature (°C) | 80 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Dielectric strength (kV/mm) | 16.1 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹⁵ |
| Dielectric constant | 2.6 |
| Material type | Extruded |
Frequently Asked Questions (FAQ)
-
What is the maximum service temperature for this sheet?
The maximum long-term service temperature is 65°C. -
Can this material be thermoformed?
Yes, it possesses superior thermoforming properties and can be rapidly thermoformed at low temperatures. -
Is this sheet suitable for outdoor use?
Yes, it is weather-resistant and suitable for various outdoor applications.
