Description
Description
The Opal Acrylic Sheet is a premium quality acrylic sheet product characterized by excellent surface hardness, durability (guaranteed for 10 years), and consistent color. This sheet comes in a wide range of white tones, ideal for applications requiring a white color palette or for light box applications. Multiple opal finishes are available from stock, making it perfect for various applications and light transmission requirements.
Edge Finishes
Our cut-to-size service offers five edge finishes:
- Saw Edge: A smooth edge with little or no chipping that has a frosted appearance.
- Milled Edge: A smooth "satin" edge with minimal striations, ideal for solvent bonding.
- Laser Cut Edge: A highly polished glossy edge produced by the intense heat generated by the laser beam; no further edge finishing is required.
- Diamond Polish: Diamond-tipped cutters rotating at up to 24,000 rpm are used to polish the edges, creating a crystal-clear finish. Some rotational marks may be discernible.
- Diamond Polish & Buff: The diamond polished edge is buffed to enhance the glossy premium appearance.
Applications
The long-term service temperature range of the Opal Acrylic Sheet is from -40°C to 80°C. Typical fields of application include interior design, retail display and signage, and point of sale. The Opal Acrylic Sheet is well-suited for CNC routing, laser cutting, and fabrication.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Sheet |
| Colour | Opal |
| Density (g/cm³) | 1.19 |
| Water absorption (%) | 0.2 |
| Elongation at break (%) | 4 |
| CLTE (10⁻⁶K⁻¹) | 77 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 80 |
| Flammability 3mm | HB |
FAQ
- What is the service temperature range? The Opal Acrylic Sheet can withstand temperatures from -40°C to 80°C.
- Can this sheet be used for CNC routing? Yes, the Opal Acrylic Sheet is well-suited for CNC routing, laser cutting, and fabrication.
- What edge finishes are available? Available finishes include Saw Edge, Milled Edge, Laser Cut Edge, Diamond Polish, and Diamond Polish & Buff.
