Description
Description
The Premium Oil-Filled Nylon 6 Green Rod is an engineering plastic known for its outstanding sliding properties, self-lubricating capabilities, and improved "stick-slip" performance. This material is designed to operate within a long-term service temperature range of -40°C to 85°C, with a short-term maximum service temperature of 160°C, making it suitable for various demanding applications.
This rod is ideal for use in mechanical engineering, packaging, and conveyor industries. Its versatility allows for efficient CNC turning, billeting, and precision grinding, ensuring precise components and parts for your projects.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Nylon 6 |
| Shape | Rod |
| Colour | Green |
| Density (g/cm³) | 1.14 |
| Water absorption (%) | 3 |
| Yield stress (MPa) | 80 |
| Elongation at break (%) | ≥50 |
| Notched impact strength (kJ/m²) | ≥3 |
| Ball indentation hardness (MPa) | 170 |
| Shore hardness (scale D) | 82 |
| Tensile modulus of elasticity (MPa) | 3200 |
| Melting temperature (°C) | 220 |
| Thermal conductivity (W/(m*K) | 0.23 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 90 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 85 |
| Service temp short term max (°C) | 160 |
| Heat deflection temperature (°C) | 75 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Oil Filled |
Applications
- Mechanical Engineering
- Packaging Industry
- Conveyor Industries
FAQs
-
What is the temperature range for the Nylon 6 Rod?
It operates from -40°C to 85°C long-term, and up to 160°C short-term. -
Can this material be machined?
Yes, it is suitable for CNC turning, billeting, and precision grinding. -
Is this rod self-lubricating?
Yes, it features self-lubricating properties for enhanced performance.
