Description
Description
The Premium Nylon 66 Extruded Black Rod is an engineering plastic renowned for its high hardness and mechanical strength. This material offers outstanding sliding properties and excellent abrasion resistance, making it ideal for various industrial applications.
With a long-term service temperature range of -30°C to 95°C and a short-term maximum service temperature of 170°C, this rod is suitable for challenging environments. It is commonly used in mechanical engineering, vehicle construction, and the building industry.
The Nylon 66 Rod is particularly well-suited for processes such as billeting, precision grinding, and CNC turning, ensuring precision and durability in finished components.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Nylon 66 |
| Shape | Rod |
| Colour | Black |
| Density (g/cm³) | 1.15 |
| Water absorption (%) | 2.8 |
| Yield stress (MPa) | 90 |
| Elongation at break (%) | ≥20 |
| Tensile modulus of elasticity (MPa) | 3400 |
| Notched impact strength (kJ/m²) | ≥2 |
| Ball indentation hardness (MPa) | 180 |
| Shore hardness (scale D) | 83 |
| Melting temperature (°C) | 260 |
| Thermal conductivity (W/(m*K) | 0.23 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 80 |
| Service temp long term min (°C) | -30 |
| Service temp long term max (°C) | 95 |
| Service temp short term max (°C) | 170 |
| Heat deflection temperature (°C) | 100 |
| Flammability 3mm | HB |
| Flammability 6mm | V2 |
| Material type | Extruded |
Applications
- Mechanical engineering
- Vehicle construction
- Building industries
FAQ
-
What is the service temperature range for Nylon 66 Rod?
- Long-term: -30°C to 95°C; short-term maximum: 170°C. -
What is the density of Nylon 66?
- The density is 1.15 g/cm³. -
Can Nylon 66 be used for precision machining?
- Yes, it is well-suited for processes like CNC turning and precision grinding.
