Description
Description
The Premium Nylon 6 Oil Filled Yellow Rod is an engineering plastic known for its excellent sliding properties, self-lubricating capabilities, and improved stick-slip properties. With a long-term service temperature range from -40°C to 85°C and a short-term maximum service temperature of 160°C, this versatile material is ideal for various applications.
Typical fields of application include mechanical engineering, the packing industry, and conveyor systems. The Nylon 6 Rod is exceptionally suited to CNC turning, billeting, and precision grinding, making it a valuable addition to your toolkit.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Nylon 6 |
| Shape | Rod |
| Colour | Yellow |
| Density (g/cm³) | 1.14 |
| Water absorption (%) | 3 |
| Yield stress (MPa) | 80 |
| Elongation at break (%) | ≥50 |
| Notched impact strength (kJ/m²) | ≥3 |
| Ball indentation hardness (MPa) | 170 |
| Shore hardness (scale D) | 82 |
| Tensile modulus of elasticity (MPa) | 3200 |
| Melting temperature (°C) | 220 |
| Thermal conductivity (W/(m*K) | 0.23 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 90 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 85 |
| Service temp short term max (°C) | 160 |
| Heat deflection temperature (°C) | 75 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Oil Filled |
Applications
- Mechanical Engineering
- Packing Industry
- Conveyor Systems
FAQ
What are the benefits of using Nylon 6 Oil Filled Rod?
Nylon 6 Oil Filled Rod offers excellent sliding properties and self-lubricating features, making it ideal for high-performance applications.
What temperature range can the Nylon 6 Rod withstand?
This material can withstand long-term temperatures ranging from -40°C to 85°C and short-term temperatures up to 160°C.
Can this material be machined?
Yes, Nylon 6 is well-suited for CNC turning, billeting, and precision grinding.
