The Premium Nylon 6 Extruded Black Rod is an engineering plastic renowned for its exceptional product characteristics, including high mechanical strength, high rigidity, and impressive UV resistance. It is designed to withstand a wide temperature range, with a long-term service temperature of -40°C to 85°C and a short-term maximum service temperature of 160°C.
Typical applications for the Premium Nylon 6 Rod include mechanical engineering, vehicle construction, and conveyor industries. This material is particularly well-suited for CNC routing, billeting, and precision grinding, making it a versatile choice for various manufacturing processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Nylon 6 |
| Shape | Rod |
| Colour | Black |
| Density (g/cm³) | 1.14 |
| Water absorption (%) | 3 |
| Yield stress (MPa) | 80 |
| Elongation at break (%) | ≥50 |
| Tensile modulus of elasticity (MPa) | 3200 |
| Notched impact strength (kJ/m²) | ≥3.0 |
| Ball indentation hardness (MPa) | 170 |
| Shore hardness (scale D) | 83 |
| Melting temperature (°C) | 220 |
| Thermal conductivity (W/(m*K) | 0.23 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 90 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 85 |
| Service temp short term max (°C) | 160 |
| Heat deflection temperature (°C) | 75 |
| Dielectric constant | 3.9 |
| Dielectric strength (kV/mm) | 20 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
The Premium Nylon 6 Rod is suitable for a variety of applications including:
- Mechanical engineering
- Vehicle construction
- Conveyor systems
FAQs
1. What are the temperature limits for Nylon 6 Rod?
The long-term service temperature range is from -40°C to 85°C with a short-term maximum of 160°C.
2. How is Nylon 6 Rod processed?
This material is well-suited for CNC routing, billeting, and precision grinding.
3. What industries commonly use Nylon 6 Rod?
It is commonly used in mechanical engineering, vehicle construction, and conveyor industries.
