Description
Description
The Premium Nylon 12 Extruded Natural Rod is a high-performance engineering plastic known for its exceptional properties. It features low moisture absorption, high stress crack resistance, and impressive impact strength. This material is designed to perform efficiently in various applications, ensuring durability and reliability.
With a long-term service temperature range of -50°C to 80°C, and a short-term maximum service temperature of 140°C, this nylon rod is versatile for use in mechanical engineering, vehicle construction, and textile industries. It is particularly well-suited for billeting, precision grinding, and CNC turning, making it an ideal choice for various manufacturing processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Nylon 12 |
| Shape | Rod |
| Colour | Natural |
| Density (g/cm³) | 1.02 |
| Water absorption (%) | 0.8 |
| Yield stress (MPa) | 50 |
| Elongation at break (%) | 200 |
| Notched impact strength (kJ/m²) | 20 |
| Ball indentation hardness (MPa) | 100 |
| Shore hardness (scale D) | 78 |
| Tensile modulus of elasticity (MPa) | 1800 |
| Melting temperature (°C) | 178 |
| Thermal conductivity (W/(m*K)) | 0.3 |
| Thermal capacity (kJ/(kg*K)) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 100 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 80 |
| Service temp short term max (°C) | 140 |
| Heat deflection temperature (°C) | 50 |
| Dielectric constant | 3.8 |
| Dielectric strength (kV/mm) | 26 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Mechanical engineering
- Vehicle construction
- Textile industries
- Precision grinding
- CNC turning
FAQ
-
What is the maximum service temperature for Nylon 12 Rod?
The short-term maximum service temperature is 140°C. -
What industries can Nylon 12 Rod be used in?
It is suitable for mechanical engineering, vehicle construction, and textiles. -
Can this material be machined?
Yes, Nylon 12 Rod is well-suited for billeting, precision grinding, and CNC turning.
