Description
Description
Medical Grade PEEK features a combination of very high rigidity, hardness, tensile strength, and bending strength (high toughness and fatigue strength), high heat deflection temperature, and excellent resistance to disinfectants and detergents. It also has an exceptionally high hydrolytic stability so that repeated sterilisation in steam is possible without any problems.
Characteristics of Medical Grade PEEK include:
- Excellent sterilisability with all standard methods (superheated steam, gamma, E-beam, EtO)
- Very high stability, rigidity, and toughness
- Very high thermal stability and heat deflection temperature
- Very high creep resistance
- Very high dimensional stability
- Very high radiation resistance
- Very high hydrolysis resistance
- Good wear properties
- Low water absorption
- Inert
These Medical Grade products are suitable for medical and pharmaceutical applications with direct body contact with tissue, bone, skin, and mucosa for up to 24 hours. All raw materials used for the medical grade products are food grade (FDA, EU 10/2011) and have been tested and evaluated by an independent accredited testing laboratory and meet the following biocompatibility requirements:
- ISO 10993-1: Evaluation and testing within a risk management process
- ISO 10993-5: Tests for in vitro cytotoxicity
- ISO 10993-12: Sample preparation and reference materials
- ISO 10993-18: Chemical characterization of materials
- USP Class VI
Typical applications include surgical instruments, dental instruments, connectors, sealing rings, spacers, dosing systems, in vitro diagnostics, grippers, holders, insulation sleeves, and primary packaging in the pharmaceutical sector.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PEEK |
| Shape | Rod |
| Colour | Natural |
| Density (g/cm³) | 1.32 |
| Water absorption (%) | 0.4 |
| Yield stress (MPa) | 115 |
| Elongation at break (%) | 16 |
| Tensile modulus of elasticity (MPa) | 4210 |
| Ball indentation hardness (MPa) | 250 |
| Notched impact strength (kJ/m²) | 4 |
| Shore hardness (scale D) | 90 |
| CLTE (10⁻⁶K⁻¹) | 25 |
FAQ
- What are the applications of Medical Grade PEEK? Typical applications include surgical instruments, dental instruments, connectors, sealing rings, and more.
- Is Medical Grade PEEK suitable for direct body contact? Yes, it is suitable for applications with direct body contact with tissue, bone, skin, and mucosa for up to 24 hours.
- What certifications does Medical Grade PEEK meet? Medical Grade PEEK meets biocompatibility requirements such as ISO 10993 and USP Class VI.
