Description
Description
The Premium Matt Black ABS Sheet is a thermoformable sheet product that offers exceptional qualities such as high rigidity and impact strength. It also features excellent chemical and abrasion resistance, along with outstanding moisture and creep resistance. This versatile material is well-suited for various applications including automotive industries, point of sale displays, and model making.
This ABS Sheet is ideal for processes such as CNC routing, vacuum forming, and bonding, making it a popular choice among professionals seeking durable materials.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | ABS |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 1.07 |
| Water absorption (%) | 0.3 |
| Yield stress (MPa) | 45 |
| Elongation at break (%) | 20 |
| Notched impact strength (kJ/m²) | 11 |
| Ball indentation hardness (MPa) | 90 |
| Shore hardness (scale D) | 78 |
| Tensile modulus of elasticity (MPa) | 2400 |
| Thermal capacity (kJ/(kg*K) | 1.2 |
| Thermal conductivity (W/(m*K) | 0.17 |
| CLTE (10⁻⁶K⁻¹) | 90 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 80 |
| Service temp short term max (°C) | 100 |
| Dielectric constant | 3.1 |
| Dielectric strength (kV/mm) | 20 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Automotive industries
- Point of sale displays
- Model making
- CNC routing
- Vacuum forming
- Bonding
FAQ
-
What is the maximum service temperature of the ABS sheet?
The maximum short-term service temperature is 100°C. -
Can this material be used for outdoor applications?
The ABS sheet has excellent weather resistance, making it suitable for outdoor use. -
Is CNC routing effective with ABS sheets?
Yes, ABS sheets are well-suited for CNC routing, allowing for precision machining.
