Description
Description
This premium composite panel features a lightweight yet rigid 3-dimensional translucent SAN inner core, bonded with external layers of high-quality acrylic. Easy to cut and install, this panel can be finished with standard accessories and profiles such as frames, handles, and hinges. The edges can also be finished with the same material used for the external layers, providing a seamless look.
Thanks to its characteristics of lightweight, stiffness, and translucency, along with the unique geometric pattern of its core, this structural panel is ideal for a wide variety of indoor applications. It excels as partition walls, wall presentations, lighting fixtures, bar and counter fronts, stair panels, balustrades, doors, walls, and ceilings. Available in a range of colors with both transparent and satin finishes, it offers versatility and aesthetic appeal.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Sheet |
| Colour | Clear |
| Density (g/cm³) | 1.19 |
| E-modulus (MPa) | 3300 |
| COE (mm/m/10ºC) | 0.6 |
| Bending strength (kg/cm) | 1200 |
| Fire classification (EN13501) | E |
| Thickness tolerance | 0.4mm +/- 10% |
| Saw tolerance (mm) | +/-1 |
| Deviation angularity (mm/1m) | 1.5 |
| Service temp long term min (°C) | -10 |
| Service temp long term max (°C) | 50 |
| Material type | Honeycomb |
Applications
- Partition walls
- Wall presentations
- Lighting fixtures
- Bar and counter fronts
- Stair panels
- Balustrades
- Doors
- Walls and ceilings
FAQ
What are the benefits of using this composite sheet?
This composite sheet is lightweight, durable, and offers excellent translucency, making it suitable for various indoor applications.
Is this material easy to work with?
Yes, the sheet is easy to cut and can be finished with standard accessories and profiles.
What finishes are available for this product?
The composite sheet is available in a range of colors with both transparent and satin finishes.
