Description
Description
The Premium Honeycomb Composite Sheet features a rigid 3-dimensional translucent SAN inner core bonded with external layers of Acrylic. This composite panel is easy to cut and can be finished with standard accessories and profiles such as frames, handles, and hinges. It can also be edged with the same material used for the external layers.
Thanks to its characteristics of lightweight, stiffness, translucency, and the unique geometric pattern of its core, this structural panel has a wide variety of indoor applications. It is excellent for use as partition walls, wall presentations, lighting fixtures, bar and counter fronts, stair panels, balustrades, doors, as well as walls and ceilings. Available in a range of colors with both transparent and satin finishes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Sheet |
| Colour | Bronze |
| Density (g/cm³) | 1.19 |
| E-modulus (MPa) | 3300 |
| COE (mm/m/10ºC) | 0.6 |
| Bending strength (kg/cm) | 1200 |
| Fire classification (EN13501) | E |
| Thickness tolerance | 0.4mm +/- 10% |
| Saw tolerance (mm) | +/-1 |
| Deviation angularity (mm/1m) | 1.5 |
| Service temp long term min (°C) | -10 |
| Service temp long term max (°C) | 50 |
| Material type | Honeycomb |
Applications
The Premium Honeycomb Composite Sheet is suitable for a variety of applications, including:
- Partition walls
- Wall presentations
- Lighting fixtures
- Bar and counter fronts
- Stair panels
- Balustrades
- Doors
- Walls and ceilings
FAQs
What is the main material of the composite sheet?
The main material is Acrylic with a honeycomb structure.
What applications can this composite sheet be used for?
It is ideal for indoor applications such as partitions, lighting fixtures, and decorative walls.
What is the fire classification of this product?
The product has a fire classification of E according to EN13501 standards.
