Description
Description
This premium honeycomb composite sheet consists of a hexagonal aluminum core (available in large or small sizes) glued between two top layers of either acrylic or PETG, depending on the application. This ultra-lightweight material reflects and refracts light within the cells, creating a soft glow that shifts with your point of view. The sheet is available in a range of colors with both transparent and satin finishes.
Being rigid and impact resistant, this composite sheet is excellent for use in partition walls, wall presentations, lighting fixtures, bar and counter fronts, stair panels, balustrades, doors, walls, and ceilings. It is easy to cut and can be finished with standard accessories and profiles, frames, handles, and hinges. The sheet can be edged with the same material used for the external layers. Please note that this product is not suitable for outdoor applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Sheet |
| Colour | Clear |
| Density (g/cm³) | 1.19 |
| Service temp long term min (°C) | -10 |
| Service temp long term max (°C) | 50 |
| E-modulus (MPa) | 3300 |
| COE (mm/m/10ºC) | 0.6 |
| Bending strength (kg/cm) | 1200 |
| Fire classification (EN13501) | E |
| Thickness tolerance | 0.4mm +/- 10% |
| Saw tolerance (mm) | +/-1 |
| Deviation angularity (mm/1m) | 1.5 |
| Material type | Honeycomb |
Applications
- Partition walls
- Wall presentations
- Lighting fixtures
- Bar and counter fronts
- Stair panels
- Balustrades
- Doors
- Walls
- Ceilings
FAQs
- Is this composite sheet suitable for outdoor use? No, this product is not suitable for outdoor applications.
- How can I cut the composite sheet? The sheet can be easily cut with standard tools.
- What colors are available? The sheet is available in a range of colors, including transparent and satin finishes.
