Description
Description
This premium honeycomb composite sheet features a design with a core formed from randomly melted polycarbonate straws of three different diameters. The core is encapsulated with glued cover sheets made from either acrylic or PETG, tailored to meet specific application requirements.
Lightweight yet rigid, this composite sheet is suitable for multiple indoor applications. It can be easily cut and finished using standard accessories, profiles, frames, handles, and hinges. The black core provides a unique optical effect, allowing visibility through the panel when viewed perpendicularly, while obstructing visibility at angles greater than 30°.
Available with either a clear gloss or clear satin finish, this composite sheet combines functionality with aesthetic appeal.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PETG Honeycomb Composite |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 1.3 |
| Service Temperature Long Term Min (°C) | -10 |
| Service Temperature Long Term Max (°C) | 50 |
| E-modulus (MPa) | 2350 |
| COE (mm/m/10ºC) | 0.5 |
| Bending Strength (kg/cm) | 1587 |
| Fire Classification (EN13501-1) | Bs1D0 |
| Thickness Tolerance | Barely |
| Saw Tolerance (mm) | +/-1 |
| Deviation Angularity (mm/1m) | 1.5 |
| Material Type | Honeycomb |
FAQ
-
What applications can the composite sheet be used for?
This composite sheet is ideal for various indoor applications due to its lightweight and rigid characteristics. -
Can the sheet be easily cut?
Yes, it can be easily cut and finished using standard accessories. -
What finishes are available?
The sheet is available in clear gloss or clear satin finishes.
