This premium composite panel features a lightweight yet rigid 3-dimensional translucent SAN inner core, bonded with external layers of acrylic. The panels are easy to cut and can be finished with standard accessories and profiles such as frames, handles, and hinges. Additionally, the edges can be finished with the same material used for the external layers.
Thanks to its lightweight, stiffness, translucency, and unique geometric pattern, this structural panel is suitable for a wide variety of indoor applications. It excels as partition walls, wall presentations, lighting fixtures, bar and counter fronts, stair panels, balustrades, doors, walls, and ceilings. Available in a range of colors with both transparent and satin finishes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Sheet |
| Colour | Light Fume |
| Density (g/cm³) | 1.19 |
| E-modulus (MPa) | 3300 |
| COE (mm/m/10ºC) | 0.6 |
| Bending strength (kg/cm) | 1200 |
| Fire classification (EN13501) | E |
| Thickness tolerance | 0.4mm +/- 10% |
| Saw tolerance (mm) | +/-1 |
| Deviation angularity (mm/1m) | 1.5 |
| Service temp long term min (°C) | -10 |
| Service temp long term max (°C) | 50 |
| Material type | Honeycomb |
Applications
This premium honeycomb composite panel is ideal for:
- Partition walls
- Wall presentations
- Lighting fixtures
- Bar and counter fronts
- Stair panels
- Balustrades
- Doors
- Walls and ceilings
FAQ
Q: Can the panel be cut to size?
A: Yes, the panel is easy to cut for customized applications.
Q: What is the maximum service temperature?
A: The maximum service temperature is 50°C.
Q: Is the panel fire rated?
A: Yes, the panel has a fire classification of E according to EN13501.
