Description
Description
The Premium High-Performance Extruded Natural Sheet is a high-quality engineering plastic renowned for its excellent dimensional stability, high flame retardance, self-extinguishing properties, and very low smoke density. This material is designed to withstand a long-term service temperature range from -60°C to 250°C, with a short-term maximum service temperature reaching up to 310°C.
Common applications for this extruded sheet include medical technology, aerospace engineering, and electrical industries. It is well suited for machining processes such as CNC milling, CNC routing, and CNC turning, making it versatile for various manufacturing needs.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | High-Performance Plastic |
| Shape | Sheet |
| Colour | Natural |
| Density (g/cm³) | 1.31 |
| Water Absorption (%) | 0.2 |
| Yield Stress (MPa) | 110 |
| Elongation at Break (%) | 20 |
| Tensile Modulus of Elasticity (MPa) | 4000 |
| Ball Indentation Hardness (MPa) | 230 |
| Shore Hardness (Scale D) | 88 |
| Melting Temperature (°C) | 343 |
| Thermal Conductivity (W/(m*K)) | 0.25 |
| Thermal Capacity (kJ/(kg*K)) | 1.34 |
| Coefficient of Linear Thermal Expansion (10⁻⁶K⁻¹) | 50 |
| Service Temperature Long Term Min (°C) | -60 |
| Service Temperature Long Term Max (°C) | 250 |
| Service Temperature Short Term Max (°C) | 310 |
| Heat Deflection Temperature (°C) | 152 |
| Dielectric Constant | 3.2 |
| Dielectric Strength (kV/mm) | 20 |
| Volume Resistivity (Ω*cm) | 4.9⋅10¹⁶ |
| Surface Resistivity (Ω) | 10¹⁸ |
| Flammability 3mm | VO |
| Flammability 6mm | VO |
| Material Type | Extruded |
Applications
- Medical Technology
- Aerospace Engineering
- Electrical Industries
FAQs
-
What is the maximum service temperature of this sheet?
The maximum short-term service temperature is 310°C. -
Can this material be machined?
Yes, it is well suited for CNC milling, routing, and turning. -
What is the density of this material?
The density of the sheet is 1.31 g/cm³.
