Description
Description
The Premium Glass Fibre Angles are pultruded in a polyester matrix to meet BS EN 13706 specifications. The fibreglass layup combines multi-layered cross-ply glass fibre fabrics, providing enhanced strength across the axis and excellent mechanical properties.
Glass Fibre offers numerous benefits, including a lightweight construction and a high strength-to-weight ratio, ensuring reliable performance even under heavy loads. Its versatility and ease of handling make it a practical, cost-effective choice for a wide range of structural applications. Additionally, its resistance to corrosion makes it ideal for demanding environments. The material can be easily machined and cut to size, allowing for customization to meet the unique requirements of your project.
Offering high performance and durability combined with ease of handling and installation, Glass Fibre is an ideal solution for various applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Glass Fibre |
| Shape | Angle Trim |
| Colour | Grey |
| Density (g/cm³) | 1.5-2 |
| Water absorption (%) | 0.5-2 |
| Construction | Pultrusion |
| Resin Matrix | Polyester |
| Fibre Orientation | Crossdirectional |
| CLTE (10⁻⁶K⁻¹) | 7.2 |
| Full Section Modulus | < 6mm thick: E17 (GPa17), 6mm & >: E23 (GPa23) |
| Tensile strength axial (MPa) | E17: 170, E23: 240 |
| Tensile strength transverse (MPa) | E17: 30, E23: 50 |
| Flexural strength axial (MPa) | E17: 170, E23: 240 |
| Flexural strength transverse (MPa) | E17: 70, E23: 100 |
| Tensile modulus axial (MPa) | E17: 1.7x10⁴, E23: 2.4x10⁴ |
| Tensile modulus transverse (MPa) | E17: 0.5x10⁴ |
Applications
- Structural installations in various environments
- Customizable for unique project requirements
- Ideal for use in corrosion-prone areas
FAQ
-
What is the weight capacity of the glass fibre angle?
It can handle heavy loads due to its high strength-to-weight ratio. -
Can this material be cut to size?
Yes, it can be easily machined and customized to fit specific needs. -
Is it resistant to corrosion?
Absolutely, it is designed for use in demanding environments.
