Description
Description
The Premium High-Performance Pressed and Planed Green Sheet is made from virgin polyethylene, known for its exceptional characteristics, including high abrasion resistance, low coefficient of friction, and high impact strength. The material offers a long-term service temperature range from -50°C to 80°C, with a short-term maximum service temperature of 130°C. Its water absorption factor is less than 0.01%, ensuring dimensional stability even in humid environments.
This versatile sheet is suitable for various applications, including bottling and food processing, mechanical engineering, and the bearing and packing industries. It is ideal for CNC routing, CNC milling, and CNC turning, making it a preferred choice for precision machining tasks.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PE1000 (UHMWPE) |
| Shape | Sheet |
| Colour | Green |
| Density (g/cm³) | 0.93 |
| Yield stress (MPa) | 20 |
| Elongation at break (%) | >200 |
| Shore hardness (scale D) | 63 |
| Tensile modulus of elasticity (MPa) | 680 |
| Melting temperature (°C) | 135 |
| Thermal conductivity (W/(m*K)) | 0.4 |
| Thermal capacity (kJ/(kg*K)) | 1.9 |
| CLTE (10⁻⁶K⁻¹) | 150…230 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 80 |
| Service temp short term max (°C) | 130 |
| Heat deflection temperature (°C) | 79 |
| Dielectric constant | 2.3 |
| Dielectric strength (kV/mm) | 45 |
| Volume resistivity (Ω*cm) | >10¹⁴ |
| Surface resistivity (Ω) | >10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Bottling and food processing
- Mechanical engineering
- Bearing and packing industries
- CNC routing, milling, and turning
FAQ
-
What is the maximum service temperature for this sheet?
The maximum short-term service temperature is 130°C. -
Is this sheet suitable for humid environments?
Yes, it has a low water absorption factor of <0.01%, making it dimensionally stable. -
Can this material be machined?
Yes, it is well-suited for CNC machining processes.
