Description
Description
Our Premium Glass Fibre Tubes are pultruded using a high volume fraction of fibreglass in a polyester matrix to BS EN 13706 specifications. Tubes with diameters up to 32mm are unidirectional glass fibre tubes with a smooth surface that are designed to provide excellent resistance to bending. For diameters over 32mm, the fibreglass layup is a combination of multi-layered cross-ply fabrics, providing greater hoop strength that resists both bending and torsional forces.
Glass Fibre Tubes offer numerous benefits, including a lightweight construction and a high strength-to-weight ratio that ensures reliable performance even under heavy loads. Their versatility and ease of handling make them a practical, cost-effective choice for a wide range of structural applications, while their resistance to corrosion makes them ideal for use in demanding environments. They can be easily machined and cut to size, allowing for customization to meet the unique requirements of your project.
Offering high performance and durability combined with ease of handling and installation, these tubes are an ideal solution for a wide range of applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Glass Fibre |
| Shape | Tube |
| Colour | Grey |
| Density (g/cm³) | 1.8 |
| Water absorption (%) | 0.5-2 |
| Construction | Pultrusion |
| Resin Matrix | Polyester |
| Fibre Orientation | < 32mm diameter - Unidirectional |
| > 32mm diameter | Crossdirectional |
| CLTE (10⁻⁶K⁻¹) | 7.2 |
| Barcol hardness | 40-70 |
| Tensile strength (MPa) | 500 |
| Flexural strength (MPa) | Up to 13.8 mm dia: 650 |
| Over 13.8 mm dia | 450 |
| Compressive strength (MPa) | Up to 13.8mm dia: 190 |
| Over 13.8mm dia | 150 |
| Tensile modulus (MPa) | 2.7x10⁴ |
| Flexural modulus (MPa) | Up to 13.8mm dia: 3.0x10⁴ |
| Over 13.8mm dia | 2.4x10⁴ |
| Heat distortion temp (°C) | Not specified |
Applications
- Structural components in construction
- Weight-sensitive applications
- Corrosion-resistant environments
- Custom fabrication projects
FAQ
-
Can these tubes be cut to size?
Yes, they can be easily machined and cut to your specifications. -
What environments are these tubes suitable for?
Their corrosion resistance makes them ideal for demanding environments. -
What is the maximum diameter available?
We offer tubes with diameters exceeding 32mm with enhanced strength.
