Our Premium Glass Fibre Square Tubes are pultruded in a polyester matrix to BS EN 13706 specifications. The fibreglass layup is a combination of multi-layered cross-ply glass fibre fabrics, providing enhanced across-axis strength and excellent mechanical properties.
Glass Fibre Tubes offer numerous benefits including a lightweight construction and a high strength-to-weight ratio that ensures reliable performance even under heavy loads. Their versatility and ease of handling make them a practical, cost-effective choice for a wide range of structural applications, while their resistance to corrosion makes them ideal for use in demanding environments. They can be easily machined and cut to size, allowing for easy customization to meet the unique requirements of your project.
Offering high performance and durability combined with ease of handling and installation, Glass Fibre Tubes are an ideal solution for various applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Glass Fibre |
| Shape | Square Tube |
| Colour | Black |
| Density (g/cm³) | 1.8 |
| Water absorption (%) | 0.5-2 |
| Construction | Pultrusion |
| Resin Matrix | Polyester |
| Fibre Orientation | Crossdirectional |
| CLTE (10⁻⁶K⁻¹) | 7.2 |
| Barcol hardness | 40-70 |
| Tensile strength (MPa) | 500 |
| Flexural strength (MPa) | Up to 13.8 mm dia: 650 |
| Over 13.8 mm dia | 450 |
| Compressive strength (MPa) | Up to 13.8mm dia: 190 |
| Over 13.8mm dia | 150 |
| Tensile modulus (MPa) | 2.7x10⁴ |
| Flexural modulus (MPa) | Up to 13.8mm dia: 3.0x10⁴ |
| Over 13.8mm dia | 2.4x10⁴ |
| Heat distortion temp (°C) | 125-145 |
| Dielectric strength (kV/mm) | 25 |
| Surface resistivity (Ω) | 10¹⁰-10¹⁵ |
| Volume resistivity (Ω) | 10¹⁵ |
FAQ
-
What are the benefits of using Glass Fibre Tubes?
Glass Fibre Tubes offer a high strength-to-weight ratio, corrosion resistance, and versatility, making them suitable for various structural applications. -
Can these tubes be cut to size?
Yes, Glass Fibre Tubes can be easily machined and cut to size to meet your project requirements. -
What is the typical density of Glass Fibre Tubes?
The typical density is 1.8 g/cm³.
