Description
Description
The Premium Extruded White Sheet is engineered to deliver exceptional performance, featuring high strength, high heat resistance, and excellent chemical resistance. This versatile material is suitable for a wide range of applications, including chemical engineering, tank building, and ventilation manufacturing.
With a long-term service temperature range of -30°C to 100°C, and a short-term maximum service temperature of 150°C, this sheet is built to withstand demanding environments. Its properties make it well-suited for CNC routing, welding, and fabrication processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPC |
| Shape | Sheet |
| Colour | White |
| Density (g/cm³) | 0.91 |
| Yield stress (MPa) | 23 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | >40 |
| Shore hardness (scale D) | 69 |
| Tensile modulus of elasticity (MPa) | 1100 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | -30 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 85 |
| Dielectric constant | 2.5 |
| Dielectric strength (kV/mm) | 45 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Extruded |
Applications
- Chemical engineering
- Tank building
- Ventilation manufacturing
- CNC routing, welding, and fabrication
FAQs
-
What is the maximum service temperature for this sheet?
This sheet can withstand a short-term maximum service temperature of 150°C. -
Can this material be welded?
Yes, the Premium Extruded White Sheet is suitable for welding and fabrication. -
What are the key applications for this sheet?
This material is ideal for chemical engineering, tank building, and ventilation manufacturing.
