Description
Description
The Premium Extruded Beige Rod offers impressive characteristics including high strength, exceptional heat resistance, and superior chemical and corrosion resistance. This robust rod is designed to perform in a long-term service temperature range from 0°C to 100°C, with a short-term maximum service temperature of up to 150°C.
Ideal for various applications such as chemical engineering, tank building, and laboratory technology, this rod is well-suited for CNC turning, welding, and general fabrication tasks.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPH |
| Shape | Rod |
| Colour | Beige |
| Density (g/cm³) | 0.91 |
| Water absorption (%) | <0.10 |
| Yield stress (MPa) | 32 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | 4 |
| Shore hardness (scale D) | 72 |
| Tensile modulus of elasticity (MPa) | 1300 |
| Melting temperature (°C) | 167 |
| Thermal conductivity (W/(m*K)) | 0.2 |
| Thermal capacity (kJ/(kg*K)) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | 0 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 90 |
| Dielectric constant | 2.4 |
| Dielectric strength (kV/mm) | 45 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Extruded |
Applications
- Chemical engineering
- Tank building
- Laboratory technology
- CNC turning, welding, and fabrication
FAQ
Q: What is the maximum service temperature of the rod?
A: The short-term maximum service temperature is 150°C.
Q: What material is the rod made of?
A: The rod is made of PPH, which offers high strength and heat resistance.
Q: Is the rod suitable for chemical applications?
A: Yes, the rod is designed for use in chemical engineering and other industrial applications.
