These Premium clear tubes are made from UPVC and exhibit high mechanical strength, tensile strength, and hardness, while maintaining low impact strength. They possess excellent electronic insulation properties and demonstrate high chemical resistance, making them suitable for various industrial applications. The tubes can be easily glued and welded, providing versatility for a range of projects.
Designed to withstand an internal pressure of up to 10 bar with water at 23°C, these UPVC clear tubes can operate at a continuous service temperature of up to +60°C. Common applications include sight and electrical conduit tubes, water piping, and ventilation pipes.
Please note: These tubes have a slight blue/grey tint and are industrial products. Slight surface marks may be expected.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | UPVC |
| Shape | Tube |
| Colour | Clear |
| Density (g/cm³) | 1.35 |
| Water absorption (%) | 0.5 |
| Yield stress (MPa) | 38 |
| Elongation at break (%) | 10 |
| Shore hardness (scale D) | 79 |
| Tensile modulus of elasticity (MPa) | 2800 |
| CLTE (10⁻⁶K⁻¹) | 80 |
| Service temp long term max (°C) | 60 |
| Dielectric constant | 3 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | 10¹³ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | VO |
| Flammability 6mm | VO |
FAQ
-
What is the maximum service temperature for these tubes?
The maximum service temperature for these tubes is +60°C. -
What pressure can these tubes handle?
These tubes can withstand an internal pressure of 10 bar. -
What applications are these tubes suitable for?
They are suitable for sight and electrical conduit tubes, water piping, and ventilation pipes.
