Description
Description
Premium clear UPVC tubes offer exceptional mechanical properties, including high tensile strength and hardness, alongside low impact strength. These tubes exhibit excellent electronic insulation properties and high chemical resistance, making them ideal for various applications.
They are designed to withstand internal pressures between 4-25 Bar with water at a temperature of 23°C, depending on the size. The upper continuous service temperature is +60°C. Typical applications include sight and electrical conduit tubes, water piping, and ventilation systems.
Please note: The PN rating for each size is available below. These tubes may have a slight blue/grey tint and, being industrial products, slight surface marks can be expected.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | UPVC |
| Shape | Tube |
| Colour | Clear |
| Density (g/cm³) | 1.35 |
| Water absorption (%) | 0.5 |
| Yield stress (MPa) | 38 |
| Elongation at break (%) | 10 |
| Shore hardness (scale D) | 79 |
| Tensile modulus of elasticity (MPa) | 2800 |
| CLTE (10⁻⁶K⁻¹) | 80 |
| Service temp long term max (°C) | 60 |
| Dielectric constant | 3 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | 10¹³ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | VO |
| Flammability 6mm | VO |
Applications
- Sight and electrical conduit tubes
- Water piping
- Ventilation pipes
Frequently Asked Questions
-
What is the maximum internal pressure these tubes can handle?
They can handle internal pressures between 4-25 Bar at 23°C. -
What is the service temperature for these UPVC tubes?
The upper continuous service temperature is +60°C. -
Are there any color options available?
These tubes are clear with a slight blue/grey tint.
