Description
Description
Premium Engineering Grade Extruded Clear Polycarbonate Sheet is a high-performance, amorphous thermoplastic characterized by its high dimensional stability, low moisture absorption, and excellent rigidity. This versatile material can withstand long-term service temperatures ranging from -40°C to 115°C, with a short-term maximum service temperature of 140°C. It has a water absorption factor of just 0.2%, ensuring dimensional stability even in humid environments.
Typical applications for this Premium Polycarbonate Sheet include industries such as electrical and electronics, safety engineering, and vehicle construction. It is well-suited for CNC routing, CNC milling, and CNC turning, making it a preferred choice for various manufacturing processes.
It is important to note that Engineering Grade Polycarbonate is not optically clear and should be selected for its technical and mechanical properties rather than aesthetic qualities.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Engineering Grade Polycarbonate |
| Shape | Sheet |
| Colour | Clear |
| Density (g/cm³) | 1.2 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 65 |
| Elongation at break (%) | 80 |
| Notched impact strength (kJ/m²) | 20 |
| Ball indentation hardness (MPa) | 130 |
| Shore hardness (scale D) | 82 |
| Tensile modulus of elasticity (MPa) | 2300 |
| Thermal conductivity (W/(m*K)) | 0.21 |
| Thermal capacity (kJ/(kg*K)) | 1.2 |
| CLTE (10⁻⁶K⁻¹) | 70 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 115 |
| Service temp short term max (°C) | 140 |
| Heat deflection temperature (°C) | 135 |
| Dielectric constant | 3 |
| Dielectric strength (kV/mm) | 30 |
FAQs
-
What is the temperature range of this polycarbonate sheet?
It can withstand long-term temperatures from -40°C to 115°C, with a short-term maximum of 140°C. -
Is this polycarbonate sheet suitable for machining?
Yes, it is ideal for CNC routing, milling, and turning. -
Can it be used in humid environments?
Yes, it has a low water absorption factor of 0.2%, ensuring stability in humid conditions.
